5.5
Antennas
Table 3: Antenna Part Numbers
Description
Iridium Edge Antenna inc. Mounting Bracket & mounting hardware
C-Nav289 GNSS Antenna Kit
Table 4: Edge Supplied Equipment Description and Part Numbers
Description
Iridium Edge Antenna Bundle
Includes the f ollowing items:
Iridium Edge Antenna
Iridium Edge Mounting Bracket Kit
Washer, Split Lock, M4
Screw, Round Button Head, M4
Washer, Plain, M4
Nut, Hex, Nyloc M4
Please note:
The X1 receiver requires a GNSS antenna and an Iridium Edge antenna to f unction correctly.
The LTE antenna adds additional diagnostic capabilities, but is not a system requirement
5.6
Electrical Power
5.6.1 AC Power Supply Kit
An AC Power Supply Kit is included f or those with a requirement to connect via AC power.
Table 5: AC Power Supply Kit - Part Numbers
Description
AC/DC Power Supply Unit (w/locking connector)
UK plug to PSU's IEC C13 plug, 2m
US plug to PSU's IEC C13 plug, 2m
EU plug to PSU's IEC C13 plug, 2m
CNAV-MAN-061
Revision B
C-NavX1 GNSS Receiver User Manual
DOC-TEM-28-NUM Rev A Uncontrolled copy when printed
Part Number
CNV-A-IRDM-EDGE-B
CNVAT1675-289B
Part Number
CNV-A-IRDM-EDGE-B
CNV-A-IRDM-EDGE-1
CNV-A-MTGBKT-K IT-1
0511513
0521420
0528330
0528344
Part Number
CNV-C-PSU-X1-2-2
CNV-C-PWR-UK-2-1
CNV-C-PWR-US-2-1
CNV-C-PWR-EU-2-1
Page 21 of 111
