5.3

Supplied Equipment

Table 1: C-NavX1 Supplied Equipment Description and Part Numbers
Description
C-NavX1 Receiver Kit
Includes the f ollowing items:
C-NavX1 ( LEO) GNSS Sensor
4-Way MAIN Spider Cable Power/USB/RS232(x2)
3-Way AUX Spider Cable 1PPS(BNC)/RS422(x2)
Ethernet Cable RJ45 connector(x1)
AC/DC Power Supply Unit
UK plug to PSU's IEC C13 plug, 2m
US plug to PSU's IEC C13 plug, 2m
EU plug to PSU's IEC C13 plug, 2m
Unterminated DC Power Cable
C-NavX1 Mounting Brackets
LTE Paddle Antenna
USB Flash Drive
CNAV-MAN-061
Revision B
C-NavX1 GNSS Receiver User Manual
(Locking)
DOC-TEM-28-NUM Rev A Uncontrolled copy when printed
Part Number
CNV-CX1- MAX-1-1
CNV-X1- MAX-1-1
CNV-C-MAIN-X1-2-1
CNV-C-AUX-X1-2-1
CNV-C-ETH-X1-2-1
CNV-C-PSU-X1-2-2
CNV-C-PWR-UK-2-1
CNV-C-PWR-US-2-1
CNV-C-PWR-EU-2-1
CNV-C-PWR-UT-2-1
CNV-R-MTGBKT-KIT
CNV-A-LTE-PAD-1
CNV-USB-CUS-1
