11.2.7 Poynting LTE Antenna Specifications

Table 36: Poynting LTE Antenna Specification Sheet

Part Number
RF Specifications
Polarization
Frequency bands:
Peak Gain
VSWR
Input Impedance
Environmental
Operating Temperature
Storage Temperature
Water/Dust
Mechanical
Cable Connector
Dimensions
Weight
Mounting
CNAV-MAN-061
Revision B
C-NavX1 GNSS Receiver User Manual
CNV-A-LTE-PYG-1
Linear Vertical
450-470 MHz
698-960 MHz
1710-2700 MHz
7 dBi
≤ 2.5:1 across 90% of the band
50 Ohms (Nominal)
-40 C to + 80 C (-40 F to 176 F)
-40 C to + 80 C (-40 F to 176 F)
IP68
N Female
560 x 75 mm (inc. Marine Bracket)
0.576kg
Marine Adapter (1'' -14 TPI) & L-bracket (Ø30-50mm
Pole)
