Please note:
• Never open or otherwise tamper with the device enclosure screws or connectors or you will void
the warranty.
• Ensure that the device is installed securely.
• Do not install or use your device in damp or wet conditions and always avoid installing the
device where it may be dripped on or splashed by any substance.
• Do not install your device in a location that is subject to excessive heat, humidity, dust, or
vibration.
• Always connect the device to a suitable power supply
Ref er to Figure 1 f or the steps below.
1. Use one of the three supplied interf ace cables f or communications:
•
Ethernet (CNV-C-ETH-X 1-2-1): Connect the Ethernet connector of the cable to ETHERNET at the rear
of C-NavX1 GNSS receiver. Connect the RJ45 end to the computer or C-NaviGator III CDU.
•
4-way spider Cable (CNV-C-MAIN-X1-2-1): Connect the M16 connector of the cable to MAIN
connector at the rear of C-NavX1 GNSS receiver. Connect the Port 1 DB9S end to the computer or C-
NaviGator III CDU. C-Nav Controller sof tware uses a Baud Rate of 115200.
•
4-way spider Cable (CNV-C-MAIN-X1-2-1): Connect the M16 connector of the cable to MAIN
connector at the rear of C-NavX1 GNSS receiver. Connect the USB V2.0 connector to a PC or C-
Navigator. The PC will treat it as an additional serial port, no new driver sof tware is required to be
loaded.
•
3-way spider Cable (CNV-C-AUX-X1-2-1): Connect the M16 connector of the cable to AUX connector
at the rear of C-NavX1 GNSS receiver. These RS422 connection can be used f or output to DP systems.
Please note:
Only two concurrent devices can be used to control the C-NavX1: one serial (including the USB
virtual serial port and one Ethernet local port
2. Mount the supplied GNSS antenna. Locate the antenna in an area with a 360° clear view of the sky.
3. Connect the TNC connector on one end of a C-Nav approved GNSS antenna cable to the GNSS antenna.
Connect the other end of the cable to the TNC connector, labeled GNSS, at the rear of the C-NavX1
GNSS receiver.
4. Mount the supplied Iridium Edge antenna using the supplied mounting bracket.
5. Connect the M12 connector of the Iridium Edge antenna cable to the 20cm pigtail of the Edge antenna.
