BARRON EXITRONIX NFT Series Installation Instructions

Download this manual

NFT Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations

if applicable.

• Do not mount near gas or electrical heaters.

• Do not use outdoors.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering

by unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 24 hours before first use.

• For use with metal enclosed wiring systems.

10070328 REV1 - 07/24

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Technical Support

■ (623) 580-8943 ■ technicalsupport@barronltg.com

800-533-3948 www.barronltg.com

Need help?

Do you have a question about the EXITRONIX NFT Series and is the answer not in the manual?

Page 1 NFT Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
Page 2 NFT Series Installation Instructions Wall/Ceiling Mount - Back Power Feed (Fig. 2) Fig. 1 1. Insert a flat blade screwdriver into the two slots to remove front cover from backplate. (Fig 1). Use Screwdriver to Pry Open Remove the knockout hole on the center of the backplate. Then remove the knock outs on the backplate that correspond to the junction box holes to be used.
Page 3 NFT Series Installation Instructions Wiring Diagram (Fig. 4) Fig. 4 Remote Heads Connection - 9.6V, 5.4W Max (Option) 1. Remove ground male connector from the female connector. (Fig. 5) 2. Plug the remote male connector into the female connector. (Fig. 6) 3.
Page 4 NFT Series Installation Instructions 2. Dual color LED lamp indicator shows the following status: • Green color: On / Ready Blinking: Testing • Red color: (Service Alert) • Service Alert LED Code (Red color LED lamp indicator) One blink ON/pause (4 seconds) Battery is not connect Two blinks ON/pause...
