BARRON Exitronix CRL Series Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
1. Loosen all (4) ceiling bracket wing nuts half way for ease of installation. Hang fixture on ceiling T-bars using the
ceiling brackets. (Fig. 1)
2. Tighten all ceiling bracket wing nuts to secure fixture in place. Adjust slot placement of ceiling brackets accordingly to
adjust enclosure opening to be level with the inside surface of the T-bar. (Fig. 2a, 2b)
a. Additional chains or cabling shall be used for enclosure securement. (Fig. 2)
3. Remove (4) #6-32 x 3/4" flat head screws from cover. (Fig. 3)
Fig. 1
10070166 Rev 4 - 04/19

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!
INSTALLATION AND OPERATION INSTRUCTIONS
Fig. 2a
Wing Nuts
Bracket

INSTALLATION INSTRUCTIONS

Fig. 2b
1
CRL SERIES
Fig. 3
800.533.3948 • www.barronltg.com
6-32 x 3/4" flat
head screws
