Generac Power Systems GP Series Diagnostic Repair Manual page 75

Electrical Schematic, LP3250 Brushless Alternator Drawing No. 0J2561-B
ALTERNATOR BLOCK
W
Gy
R
W
MAIN
WINDINGS
EXCITER
WINDING
ROTOR
WINDING
BRUSH ASSEMBLY
ENGINE SWITCH
LEGEND
IG E S
OFF
ON
Diagnostic Repair Manual
W (33)
Gy (44)
15A/1P
C.B.
R (11)
15A/1P
C.B.
W (22)
G/Y
Y
Y
Bu
AVR
Br
Bu
Y
WIRE LEGEND
W WHITE Br BROWN
G GREEN Gy GRAY
R RED Y YELLOW
Bu BLUE Bl BLACK
CONTROL PANEL BLOCK
W
Gy
R
W
Gy
W (33)
W (22)
120V 20A 120V 20A
G/Y
5-20R 5-20R
DUPLEX DUPLEX
G/Y
ENGINE S.W.
E
G/Y
Y
Y
OIL LEVEL
SWITCH
CB 1-POLE LEGEND
GENERATOR MODEL
LP3250
Section 6 Electrical Data
AC OUTPUT
G/Y
R
X
G
R Gy W
Y WHT
120/240V 20A
G/Y
L14-20R
TWISTLOCK
IG
Bl
Bl
Bl
Bl
Bl
SPARK PLUG
OIL ALERT IGNITION
COIL
ENGINE BLOCK
CB RATING
15 AMP
69
