Generac Power Systems GP Series Diagnostic Repair Manual page 49

ITEM QTY. DESCRIPTION
1 1 FRAME PARTS
2 1 ASSY CRADLE BASE
3 1 CRADLE END
4 1 PANEL RAIL
5 1 BACK RAIL
6 10 CURVED HEAD BOLT 5/16-18 x
1.625" LONG
7 10 CAP NUT LOCKING 5/16-18, 5/16"
OF THREAD
8 1 ENGINE/ALT PARTS
9 1 ENGINE, 389cc W/O MUFFLER
10 4 VIB MOUNT RUBBER 1.38 x 1.0 x 5/
16-18 MALE/FEMALE
11 4 WASHER LOCK M8-5/16
12 4 SCREW HHC 5/16-18 x 1-1/4 G5
13 4 NUT LOCK FLG 5/16-18
14 1 ALTERNATOR 6500W METRIC
TAPER SHAFT
15 1 SCROLL, ALTERNATOR, SKU
16 3 SCREW HHC M5-0.8 x 8 PC8.8
17 1 ELECTRICAL PARTS
18 1 ASSY RCP PANEL 30A RD NOHR
MTR
19 1 ASSY POWER LEADS
20 4 SCREW PPPH #8-16 x 1/2" BZC
21 1 ASSY GND WIRE PNL TO ALT
22 1 ASSY GND WIRE ALT TO BASE
23 1 WASHER LOCK SPECIAL 1/4"
24 1 LUG SLDLSS #2-#8 x 17/64 CU
25 1 SCREW HHTT M6-1.0 x 25
26 1 FUEL TANK PARTS 6.6GL
27 1 FUEL TANK ASSY 6.6 GAL
28 4 SCREW HHTT M8-1.25 x 20
Diagnostic Repair Manual
ITEM QTY. DESCRIPTION
29 1 EXHAUST PARTS
30 1 BRACKET, MUFFLER SHIELD,
BOTTOM
31 1 ASSY MUFFLER, 389cc
32 1 BRACKET, MUFFLER SHIELD TOP
33 1 GASKET, EXHUAST. 389cc
34 8 SCREW HHTT M6-1.0 x 12
35 4 WASHER FLAT 5/16-M8 ZINC
36 4 WASHER LOCK M8-5/16
37 4 SCREW HHC M8-1.25 x 12 G8.8 FT
38 2 STUD M8-125 x 35 G5 ZINC
39 2 HEX NUT M8-1.25 G8 CLEAR ZINC
40 4 SCREW HHC M6-1.0 x 16 C8.8
41 1 SPACER.34 x.62 x.590 ST/ZNC
42 1 SCREW HHC M8-1.25 x 30 C8.8
43 1 ACCESSORY KIT
44 1 ASSY HANDLE LH
45 4 CARRIAGE HEAD BOLT 5/16-18 x
1.75" LONG
46 2 CAP NUT LOCKING 5/16-18, 5/16"
OF THREAD
47 1 ASSY HANDLE RH
48 2 TIRE 9.5" DIA RUN FLAT PLASTIC
HUB/RUBBER TREAD
49 2 SCREW HHFC 1/2-13 x 4.5 ZBC
50 2 NUT LOCK HEX 1/2-13 NYL INS
51 1 FRAME, BENT, FOOT BLACK 03
52 2 RUBBER FOOT
53 4 NUT LOCK FLG 5/16-18
54 2 WASHER FLAT 5/16-M8 ZINC
55 2 SCREW HHC 5/16-18 x 1/2 G5
Section 5 Major Disassembly
43
