Generac Power Systems GP Series Diagnostic Repair Manual page 55

ITEM QTY. DESCRIPTION
1 1 CRADLE END
2 1 BACK RAIL
CURVED HEAD BOLT 5/16-18 x
3 10
1.625" LONG
CAP NUT LOCKING 5/16-18
4 10
THREAD, 5/16" OF THREAD
5 1 PANEL RAIL
6 1 ASSY CRADLE BASE
10 3 WASHER LOCK M8-5/16
11 3 SCREW HHC 3/8-16 x 1-1/4 G5
12 1 SCREW HHC 5/16-24 x 1-1/4 G5
13 2 SCREW HHC 5/16-18 x 1-1/4 G5
14 3 WASHER LOCK M10
15 8 NUT LOCK FLG 5/16-18
16 1 ALTERNATOR, 7000W
VIB MOUNT RUBBER 1.38 x 1.0 x 5/
17 2
16-18 MALE/FEMALE
18 1 ENGINE, GH410
19 1 BRACKET, MOUNT
VIB MOUNT RUBBER 1.38 x 1.0 x 5/
20 2
16-18 M/M
21 2 WASHER LOCK M6-1/4
22 2 WASHER FLAT 5/16-M8 ZINC
23 2 WASHER FLAT 1/4-M6 ZINC
24 2 SCREW HHC 5/16-18 x 1-1/2 G5
25 2 SCREW HHC M6-1.0 x 16 C8,8
BRACKET, MOUNTING, MUFFLER
26 1
410
CLAMP HOSE.38-.87 [NOT SHOWN,
27 1
FUEL HOSE]
28 1 CAPACITOR, VOLTAGE REG VS
Diagnostic Repair Manual
ITEM QTY. DESCRIPTION
30 1 LUG SLDLSS #2-#8 X 17/64 CU
31 1 WASHER LOCK SPECIAL 1/4"
32 4 SCREW PPPH #8-16 x 1/2" BZC
33 1 ASSY GND WIRE ALT TO BASE
RECEPTACLE PANEL 30A RND W/
34 1
HR MTR
35 1 SCREW HHTT M6-1.0 x 25 BP
55 1 ACCESSORY KIT
56 1 ASSY HANDLE LH
57 4 CHB CUSTOM 5/16 18 x 46MM LONG
CAP NUT LOCKING 5/16-18, 5/16" OF
58 2
THREAD
59 1 ASSY HANDLE RH
TIRE 9.5" DIA RUN FLAT PLASTIC
60 2
HUB/RUBBER TREAD
61 2 SCREW, HHC 1/2"-13 x 4-1/2" LONG
NUT, LOCK HEX 1/2-13 NYLON
62 2
INSERT
63 1 FRAME, BENT, FOOT
64 2 RUBBER FOOT
65 4 NUT LOCK FLG 5/16-18
66 2 WASHER FLAT 5/16-M8 ZINC
67 2 SCREW HHC 5/16-18 X 1/2 G5
68 1 FRAME, BENT, FOOT SUPPORT
69 2 WASHER FLAT 1/2 ZINC
70 4 SCREW HHTT M8-1.25 X 20
FUEL TANK ASSY 8.0 GAL
71 1
PORTABLE
72 1 FUEL CAP-VENTED
Section 5 Major Disassembly
49
