LED
Button B
For SCY-2DALI Models
The following LEDs indicate the different status of the gateway:
LED
Run
Error
Eth. Link
Eth. Spd
Port A TX/RX
Port B TX/RX
LED for Button A
LED for Button B
Buttons
For SCY-1DALI Models
Pushbutton
Button A – DALI
Button B
For SCY-2DALI Models
Button A: Press the button once to broadcast a RECALL_MAX_LEVEL for 30 seconds. Press the button again to broadcast an OFF.
Note that when having a pen drive connected to the gateway's USB connector, press button A to save the project or/and the logs to the
pen drive. This behavior can be configured through SOLSTYCE Configuration software. Refer to the SOLSTYCE Configuration software
user guide.
Button B: Press the button once to send an I-Am message to the network.
When having a pen drive connected to the gateway's USB connector, press button B to download a project or/and a firmware version
from the pen drive to the gateway.
The gateway will download the last saved project. The project/firmware must be located in the pen drive root memory, not inside a folder.
This function of button B applies to BACnet.
This behavior can be configured through SOLSTYCE Configuration software. Refer to the SOLSTYCE Configuration software user guide.

Factory Reset

To return to factory settings, press and hold both Button A and Button B simultaneously for five seconds. The LED lights on the device will fast-blink sev-
eral times during this process.
Once the buttons are released, the LED lights will slow-blink to indicate the device is returning to the factory default state. This process can take up to 90
seconds. When the factory reset is complete, the gateway will reset and try boot in standard mode with factory default settings.
Color Description
After 30 secs of not pushing the button, the LED turns OFF and next time the button
is pushed it will begin with RECALL_MAX_LEVEL
Off/Yellow Not used
Color Description
Off No power
Green The device is powered and running
Off No error
Red Error
Off No connection
Green Connection established
Off No transmission
Yellow Transmitting data
Off No activity
TX blinking green Data packet transmitted to the DALI A network
RX blinking yellow Data packet received from the DALI A network
Off No activity
TX blinking green Data packet transmitted to the DALI B network
RX blinking yellow Data packet received from the DALI B network
Red This LED turns to steady red for 30 seconds when you press Button A
Green Link with BACnet/IP established
Off Button B has been pressed
Functionality
Sends to broadcast, alternatively: RECALL_MAX_LEVEL, OFF
Not used
