Led Indicators - Distech Controls SOLSTYCE Series Installation Manual

Modules Capacity
There are different models of SOLSTYCE modules with different capacity. The table below shows the capacity for the SCY-2DALI models.
Element
Number of DALI channels
Number DALI ECGs
addresses per line
Number DALI Sensors
addresses per line
Maximum number of instances
per input device
Max number of BACnet objects
per DALI device
Max number of BACnet objects
per DALI group
Maximum number of signals
per gateway
1
We recommend limiting this number to 16 when integrating push buttons. Realize that push buttons with several instances consume several signals.
The maximum number of DALI devices (ECGs and/or input devices) depends on the sum of the specific devices' current consumption. The gateway sup-
plies 230 mA to the bus to power the DALI devices, so if each input device (sensor) in the bus consumes 5 mA, then we can connect 63 ECGs (the stan-
dard defines the maximum consumption allowed for these devices is 2 mA) and 16 sensors.
63 ECGs * 2 mA + 16 sensors * 5 mA = 206 mA < 230 mA * 90%
As the standard recommends, don't use the guaranteed current to calculate the maximum number of DALI devices, but leave 10% of the current for fu-
ture expansion or tolerances.
2
This is the gateway's total number of signals regardless of whether they are ECGs, sensors, groups, etc.
DALI Supported Device Types
Supported Elements
Fluorescent lamp
Self-contained emergency lighting
LED module
Color control*
Energy data
Diagnostics and maintenance data
* xy color management not supported
Consult all signals and their characteristics in Available Applications section in the SOLSTYCE User Guide.

LED Indicators

For SCY-1DALI Models
The following LEDs indicate the Onboard LED indicators:
LED
Power
Dali
Tx
Rx
Button A
10 / 12
Max. Notes
2 Number of independent DALI channels
64 64 DALI ECGs addresses are supported per line
1
64 64 DALI Sensors addresses are supported per line
The maximum number of devices is limited by the guaranteed power supply of the DALI network and max signals.
Keep in mind when dimensioning each DALI channel. See Device Limits section for more details.
10 Number of available instances per input device.
60 Number of available signals will vary according to device type
18 Number of available signals will vary according to device type
2
10000 Can enable up to 10000 signals for the entire gateway regardless if they are ECG, Input devices,
Groups or Broadcast
Part
201
202
207
209
252
253
Color
Off
Green
Off
Tx/Rx
Off
Tx – Blinking green
Off
Rx – Blinking yellow
Off/Yellow
Description
No power
The device is powered and running
No error
Blinking green/yellow
Every data packet sent or received on the DALI link blinks
There is no activity on this port
Every data packet sent to the Modbus Client blinks
There is no activity on this port
Every data packet received from the Modbus Client blinks
Indicates status of last command sent from the button (On-RECALL_MAX_LEVEL,
Off-OFF).
Device Type
0
1
6
8
51
52
