Extron electronics IP Link IPL 250 Reference Manual page 89

General
Power .............................................. Supplied by an included external power supply
External power supply ................. 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements ........... 12 VDC, 0.5 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling ........................................... Convection, no vents
Mounting
Rack mount ........................ Yes, with optional 1U rack shelf
Furniture mount ................ Under-furniture mountable with optional kit
Projector mount ................. Yes, with optional projector mount kit
Enclosure type ............................... Metal
Enclosure dimensions ................... 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)
Product weight .............................. 0.7 lbs (0.3 kg)
Shipping weight ............................ 2 lbs (1 kg)
Vibration ......................................... ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ................................... CE, c-UL, UL, meets UL 60950 for safety.
EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI
Environmental ................... Complies with the appropriate requirements of RoHS, WEEE
MTBF ............................................... 30,000 hours
Warranty ......................................... 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(4.3 cm H x 10.9 cm W x 7.6 cm D) (Depth excludes connectors.)
IPL 250 • Reference Material A-3
