Extron electronics Control Modules ACM Specifications

Specifications — IRCM, ACM, RCM, and CM Series
General
Power
CM-3BLB, CM-9BLB, CM-19AC
Power input requirements
All other models .............. 12 VDC from an Extron MediaLink Controller (MLC) or System 5 IP Switcher
Power input requirements
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Rack mount ................................... Yes, with optional faceplate, and furniture/wall mountable with optional
Enclosure type .............................. Metal
Enclosure dimensions
IRCM-VCR, IRCM-DVD, IRCM-Tape, ACM-Tone, ACM-Level, RCM-SC, RCM-SCLT, CM-5BB, CM-3BLB
Faceplate ................... 1.4" H x 3.5" W x 0.1" D (3.5 cm H x 8.9 cm W x 0.3 cm D) (double space AAP
Boards ........................ 1.3" H x 2.6" W x 0.9" D (3.3 cm H x 6.6 cm W x 2.3 cm D)
IRCM-DVD+, IRCM-DV+, CM-20BB, CM-9BLB, CM-19AC
Faceplate ................... 2.8" H x 3.5" W x 0.1" D (7.1 cm H x 8.9 cm W x 0.3 cm D) (four space AAP plate)
Boards ........................ 2.7" H x 2.6" W x 0.9" D (6.9 cm H x 6.6 cm W x 2.3 cm D)
Product weight
IRCM-VCR, IRCM-DVD, IRCM-Tape, ACM-Tone, ACM-Level, RCM-SC, RCM-SCLT, CM-5BB, CM-3BLB
IRCM-DVD+, IRCM-DV+, CM-20BB, CM-9BLB, CM-19AC
Shipping weight ........................... 1 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL as components of the MLC 206, or MLC 226 IP, or MLC 104 IP Plus Series
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES as components of the
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
1-2
IRCM Series, ACM Series, RCM Series, and CM Series Control Modules • Specifications
12 VDC from an Extron MLC 226 IP or MLC 104 IP Plus Series MediaLink
Controller or System 5 IP Switcher
or from an optional external power suply
12 VDC, 0.02 A
12 VDC, 0.02 A
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
faceplates or AAP wall plates
plate)
(Depth excludes buttons. Allow at least 2.1" (5.3 cm) depth in the wall/furniture.)
(Depth excludes buttons. Allow at least 2.1" (5.3 cm) depth in the wall/furniture.)
0.1 lbs (<0.1 kg)
0.2 lbs (0.1 kg)
MediaLink ™ Controller; or System 5 IP Switcher
MLC 206, MLC 226 IP, or MLC 104 IP Plus Series MediaLink
System 5 IP Switcher
™
™ Controller; or
(7.52-053007-D4)
