37 SPARE AMP BUS – INPUT
Input to link the spare amplifier 100 V / 70 V output.
38 SPARE AMP BUS – OUTPUT
If the amplifier is not faulty (and so the spare amplifier is not inserted), this 100 V / 70 V output
is directly linked to the SPARE AMP BUS – INPUT
load.
39
(UP 9501) SPEAKER LINE OUT
Two 100 V / 70 V loudspeaker line outputs (LINE A1 and LINE A2) of the internal 500 W
amplifier.
39
a
(UP 9502) SPEAKER LINE OUT
Two 100 V / 70 V loudspeaker line outputs (LINE A1 and LINE A2) of the internal
amplifier channel A (250 W).
39
b (UP 9502) SPEAKER LINE OUT
Two 100 V / 70 V loudspeaker line outputs (LINE B1 and LINE B2) of the internal
amplifier channel B (250 W).
39
a (UP 9504) SPEAKER LINE OUT
100 V / 70 V loudspeaker LINE A output of the internal amplifier channel A (125 W).
39
b (UP 9504) SPEAKER LINE OUT
100 V / 70 V loudspeaker LINE B output of the internal amplifier channel B (125 W).
39
c (UP 9504) SPEAKER LINE OUT
100 V / 70 V loudspeaker LINE C output of the internal amplifier channel C (125 W).
39
d (UP 9504) SPEAKER LINE OUT
100 V / 70 V loudspeaker LINE D output of the internal amplifier channel D (125 W).
40
Power cord input (to be connected to a mains earthed socket only).
41
POWER switch (0 = OFF, I = ON).
42
Input for 48 V dc power supply (removable screw terminals) through batteries.
n : en 54-16
oTe accordinG To sTandard
same rack cabineT where There is The audio sysTem wiTh emerGency purposes
.
which iT is connecTed
T 48 V
he deTecTion of dc power supply inVolVes The impliciT condiTion ThaT The sysTem is
,
always Turned on Thus noT allowinG shuTdown of The main uniT ThrouGh The respecTiVe funcTion in
, POWER
The menu nor ThrouGh The
