SM1760IM0036 GB1
Meteoclock Wall deco
SM1760 + ASM20 - Instruction Manual
INTRODUCTION
Congratulations on your purchase of this weather station, MeteoClock Wall Deco SM1760. Please take
the time to read and understand this manual so you can begin to enjoy the convenience and features this
product has to offer.
What exactly is a Weather Station?
Lexibook digital stations measure not only the time in progress – thanks to their built-in-clock but also the
actual and upcoming weather.
The MeteoClock Wall deco SM1760 incorporates the following functions:
- Thermometer:
The temperature is displayed in real time to the nearest tenth of a degree Celsius. Thanks to its wireless
sensor, the station can detect from a distance the outdoor temperature or that of another room.
- Hygrometer:
Outdoor or indoor hygrometry is expressed in percentage of humidity in the ambient air. The ideal
ʻComfort Zoneʼ for the human body ranges from 35 to 65% hygrometry for a given temperature between
18 and 24oC.
- Barometer:
The station also monitors the atmospheric pressure in real time. It displays the weather forecast by
means of animated icons (sun, clouds, rain...) and for the next 8 to 12 hours.
And many extra features:
- Wide screen
- Extreme weather alerts
- Large digital display
- Wall Mount Holder
- Animated icons
Copyright © Lexibook 2006
SM1760IM0036 GB2
Main Display Unit SM1760
n�� Auto synchronizing radio controlled clock
(DCF-77 and MSF).
n�� Perpetual Calendar.
n�� Inside and outside temperature and humidity
display.
n�� Receives and monitors temperature and
humidity from up to 3 remote sensors via RF
technology of 433MHz.
n�� Maximum/minimum temperature and humidity
records.
n�� Temperature and humidity trend indicator.
n�� Comfort level icons.
n�� Pressure and temperature historical chart.
n�� Temperature alarm.
n�� Animated weather forecast symbols.
n�� Moon phase symbols.
n�� Temperature display in user-selectable ºC or
ºF.
n�� Battery: 3 x AA size.
2
1
FEATURES
Thermo sensor unit ASM20
n�� Drip-proof design with LCD.
n�� Socket of external sensor probe.
n�� Temperature display in user-selectable ºC or
ºF
n�� Humidity display.
n�� Transmission range: up to 40 meters in open
area
n�� Battery type: 2 x AA size
n�� Detachable cover with wall mount holder and
stand.
Copyright © Lexibook 2006
