LEXIBOOK MeteoClock SM1120 Owner's Manual

LEXIBOOK MeteoClock SM1120 Owner's Manual

Wireless weather station
Hide thumbs
Table of Contents

Advertisement

Quick Links

SM1120 + ASM20 - Owners manual
Congratulations on your purchase of this weather station, MeteoClock SM1120. Please take the time
to read and understand this manual so you can begin to enjoy the convenience and features this
product has to offer.
What exactly is a Weather Station?
Lexibook digital stations measure not only the time in progress - thanks to their built-in clock - but
also the actual weather!
The MeteoClock SM1120 incorporates different functions:
- Thermometer:
Temperature is displayed in real time to the nearest tenth of a degree Celsius. Thanks to its
wireless sensor, the station can sense from a distance the outside temperature or that of another
room!
- Hygrometer:
Outdoor hygrometry is expressed in percentage of humidity in the ambient air. The ideal "Comfort"
Zone for the human body ranges from 35 to 65% hygrometry for a given temperature in between
18 and 24ºC.
Copyright © Lexibook 2004
Wireless Weather Station
INTRODUCTION
1

Advertisement

Table of Contents
loading

Related Manuals for LEXIBOOK MeteoClock SM1120

Summary of Contents for LEXIBOOK MeteoClock SM1120

  • Page 1 What exactly is a Weather Station? Lexibook digital stations measure not only the time in progress - thanks to their built-in clock - but also the actual weather! The MeteoClock SM1120 incorporates different functions: - Thermometer: Temperature is displayed in real time to the nearest tenth of a degree Celsius.
  • Page 2 °C or °F ■ local temperature display ■ humidity display ■ receives and displays temperature and ■ transmission range: up to 40 meters in humidity readings from up to 4 remote open area ■ battery type: 2 x AA transmitter via RF technology of 433MHz ■...

  • Page 3: Getting Started

    GETTING STARTED Button placement CHANNEL: scrolls through remote channels 1-4 ALARM/AM/PM/°C/°F: toggles between °C and °F, 12 and 24 hour format, turns alarm on/off; clears temperature alarm presets MODE/SNOOZE: scrolls through time, alarm and temperature alarm set points (high/low); activates alarm snooze UP/HOUR/MAX: scrolls through hours;...
  • Page 4 HOUSE CODE will flash for 8 seconds Select HOUSE CODE (1-15) by pressing °C/°F and then press SET Transmitters for each receiver must be set to the same HOUSE CODE and pressing SET CHANNEL will flash for 8 seconds Select CHANNEL(1-4) by pressing °C/°F and then press SET Humidity &...
  • Page 5 Manual-Learn (Searching for Remote Signals) If a new remote transmitter is added or if signal is lost (outdoor display blinking), learn function must be executed again. Press & hold ALARM/AM/PM/°C/°F for 3 seconds to start.
  • Page 6 Select alarm mode using MODE/SNOOZE. Select hour using UP/HOUR/MAX. Select minute using DOWN/MINUTE/MIN. In alarm mode, press ALARM to toggle alarm On and Off. When alarm sounds, will flash . Press MODE/SNOOZE to snooze the alarm for 5 minutes. After that the alarm will sound again.

  • Page 7: Weather Display

    Check Local Temperature Local temperature displays instantly after batteries are inserted. Check Remote Temperature & Humidity Press CHANNEL to toggle between Channel 1, 2, 3 and 4. Temperature and humidity readings will alternately display on the receiver. °C or °F Temperature Display Toggle between °C and °F by pressing ALARM/PM/AM/°C/°F in clock mode.
  • Page 8 The trend indicator shows the trend of temperature and humidity determined by the particular transmitter in the past half-hour interval. Weather report symbols The receiver is able to monitor and display the weather status based on collected data from Channel 1. About Freeze Warning * Snow symbol will flash to warn of 'snowing'.

  • Page 9: Temperature Alarm

    TEMPERATURE ALARM The temperature alarm function allows you to have an alarm sound if the temperature rises above or drops below a particular set point. High temperature alarm Scroll to high temperature alarm mode using MODE/SNOOZE. or existing preset will flash.

  • Page 10: Other Features

    When alarm sounds, the sounding channel is displayed, and flashes to indicate whether it is the high or low temperature alarm. Press any button to shut off alarm. To clear high/low temperature alarm Select high/low temperature alarm set point using MODE/SNOOZE.

  • Page 11: Troubleshooting

    ALARM/PM/AM/°C/°F for 3 seconds until a not match. beep is heard. Temperature reading of the outdoor Ensure the remote transmitter is out of direct remote transmitter seems too high. sunlight, and away from sources of heat. Receiver is no longer receiving Repeat the learning procedures.

  • Page 12: Warranty

    WARRANTY This product is covered by our two-year warranty. To make use of the warranty or the after-sales service, please contact your retailer and supply proof of purchase. Our warranty covers material or installation-related defects attributable to the manufacturer, with the exception of wear caused by failure to respect the instructions for use or any unauthorised work on the equipment (such as dismantling, exposure to heat or damp, etc.).
