Zip HYDROTAP G5 BCHA20 Installation Instructions

6
Connect the water supply
All fittings are supplied apart from the isolation valve.
Valves and fittings
!
must be sealed
with PTFE tape.
Vented Arc and Cube Vented Classic
Braided hose
1/2" BSP adaptor
Flow restrictor
Mains water
Isolation valve
(not supplied)
Isolation valve
(not supplied)
Strainer
2x male adaptor
1/2" BSP adaptor
Braided hose to
Command Centre
MAINS inlet (supplied
with Command Centre)
Mains Arc Cube and Classic
Hot water isolation valve
(not supplied)
1/2" BSP
adaptor
MAINS IN
Braided hose
to mixer tap
BLUE - cold
RED - hot
7
Mains In
Mixer in
Mixer out
8
MAINS IN
Wipe surfaces with a damp cloth and then wipe dry
to mixer tap
with a clean, dry cloth. Do not use strong, corrosive or
abrasive cleaning materials.
T piece
Mains water
67 - 77 Allingham Street, Condell Park,NSW 2200
Mains water isolation
Postal: Locked Bag 80, Bankstown 1885, Australia
valve (not supplied)
(+612) 9796 3100 Free Call (Aust): 1800 947 827
0345 6 005 005 sales@zipindustries.co.uk
Command Centre connections
Mains potable water supply.
Blue marked braided hose from mixer tap.
Red marked braided hose from mixer tap.
Cleaning and general maintenance
WMK25927 WM-025480
AS/NZS 3718 AS/NZS 3718
Zip Water (Aust) Pty Ltd
ABN 46 000 578 727
www.zipwater.com
Zip Water UK
Trafalgar House,
Rash's Green, Dereham,
Norfolk, NR19 1JG
specify.zipwater.co.uk
Installation instructions
Zip
Mixer Taps
Arc, Cube, Classic
Vented and Mains
Australia
Visit our website and download the manuals
UK
