- Page 1 Installation instructions & user manual Zip Miniboil Models: Boiling/Ambient, Boiling Only AFFIX PRODUCT LABEL HERE 805757 805757 v1.05 06.21 Miniboil Install Instructions...
- Page 2 Checklist Before Installation: Read the instructions. Note: Not all fittings are supplied with the appliance kit. Isolation valves are not supplied. The pressure limiting valve must be fitted as part of the kit. Check the water quality to determine if extra filtration will be required. Check the appliance rating plate and ensure correct power is available for the appliance.
-
Page 3: Table Of Contents
Contents Contents WARNINGS AND PRECAUTIONS ........4 Technical specification ..........5 Installation requirements ..........5 Special tools required ............ 6 Installation ..............6 Step A - Installing the tap ..........6 Step B - Installing the filter ..........7 Step C - Installing the Command Centre ......7 Step D - Connecting the water supply ...... -
Page 4: Warnings And Precautions
Take care when lifting the Command Centre. Some units may exceed safe lifting limits. Do not lift without assistance. The weights of the units are given in the table under the heading “Installation Requirements”. Zip Miniboil Command Centre. Airflow The ambient temperatures this unit should operate within are 5ºC The appliance must be - 35ºC. -
Page 5: Technical Specification
This unit must not be positioned in an area that may be cleaned by a water jet. This unit must not be cleaned by a water jet. Technical specification MODEL Miniboil BA, Miniboil BO Capacity 1.8 Litres Power rating 1500 Watts... -
Page 6: Special Tools Required
Special tools required In addition to normal tools, the following will be required: • 35mm diameter sheet metal hole punch for sink tops (not supplied) • 35mm diameter hole saw for timber bench tops (not supplied) • Nut runner tube spanner (supplied) for fixing tap assembly. Installation Step A - Installing the tap The vertical distance between the base of the Tap... -
Page 7: Step B - Installing The Filter
Installation Step B - Installing the filter Miniboil is supplied with an external filter (see diagram below). It is important the filter be securely fixed adjacent to the under sink unit in such a manner as to allow for easy access to the filter, for service and regular replacement. -
Page 8: Step E - Connecting The Tap
Installation Filter insertion and replacement (Fig 3) Fig 3. Cartridge replacement Align the tabs of the cartridge with the filter housing and insert it up into the socket. Turn the cartridge a quarter turn to the right until it locks into position. Reverse this procedure for removal. -
Page 9: Operation
Operation Boiling Only model: Boiling water (BA model): Cold (ambient) water (BA model): Press or pull either red Press or pull the red lever, lever, and cover the Safety and cover the Safety button Press or pull the blue lever. button at the same time. -
Page 10: Font Installation
Font installation A font kit is available for this product, sold separately as an accessory. For details of the available font kits, please contact your Zip customer service provider. The font installation instructions and mounting template are supplied with the font kit. -
Page 11: Cleaning
ON. Tap loom is not connected to the unit. Check loom connection. Possible internal fault. Contact local Zip Service Provider. No water flow. Water supply isolated. Check water supply is on. Water supply not connected. Check to ensure plumbing connection is made. - Page 12 | 1800 ZIP TAP (1800 947 827) WMKA00099 AS 3498 The terms “Zip” and “HydroTap” are registered trade marks of Zip Water (Aust) Pty Ltd. Zip products described in this publication are manufactured under one or more patents and further patent applications are pending.
