4 - System Specifications
CL200 Series
Form Factor
Pico ITX (100mm x 72mm)
Processor
Intel ® Celeron ®
System
LPDDR4 onboard DRAM
memory
Processor
Intel® HD Graphics 500
Graphics
Audio
Realtek ALC233
Super I/O
Nuvoton NCT 5524
LAN1: Realtek RTL8111H
LAN
LAN2: Realtek RTL8111H
Full-length mPCIe slot (PCIe/USB/mSATA signal)
Expansion
Half-length mPCIe slot (PCIe/USB signal)
WiFi Antenna
4 x Antenna holes
Onboard
eMMC
storage
Rear I/O
Micro SD slot
Audio jack w/ Mic-in & Line-out
mini-Display Port
Front I/O
Gb LAN port
USB3.0
1 x Power button
1 x LED (on the backside of PCB)
Bottom I/O
1 x USB2.0 vertical type
1 x 12V DC-in barrel
RS 232 Box Header Connector
1 x RTC battery header
Onboard
Headers &
1 x CEC header (module population is optional)
Connectors
1x Clear CMOS, AT/ATX Jumper
CL200
(Standard- Basic) (Standard-Advance
N3350
2GB
-
-
8GB
-
1
1
2
Board-Level Assembly
CL210 CL250
d)
N3350 J3455
4GB 8GB
•
•
32GB None
•
2
2
2
2
2
2
