VICTRIX PRO V2 100 - 120 - 150 EU
25.2
VICTRIX PRO V2 100 - 120 - 150 EU FLUE ADJUSTING DEVICE (CODE: 3.034259
THE KIT INCLUDES:
1 - 1st Ø 110-125 Module connection
2 - 2nd Ø 110-125 Module connection
3 - Clapet valve Ø 125
4 - 1st Ø 200 Module manifold
5 - 2nd Ø 200 Module manifold
6 - Manifold for initial section Ø 200
7 - Drain trap unit
25.3 FLUE EXHAUST MANIFOLD KIT Ø 200 WITH FLUE ADJUSTING DEVICE
TO EXPAND VICTRIX PRO V2 100 - 120 - 150 EU (CODE: 3.034260)
THE KIT INCLUDES:
3 - Clapet valve Ø 125
5 - Additional Ø 200 module manifold
8 - Additional Ø 110-125 module manifold
Modules
2 VICTRIX PRO V2 100-120-150 EU
3 VICTRIX PRO V2 100-120-150 EU
4 VICTRIX PRO V2 100-120 EU
5 VICTRIX PRO V2 100-120 EU
FLUE EXHAUST MANIFOLD KIT Ø 200 WITH
200 Ø Flue manifold kit
code: 3.034259
N° 1
N° 1
N° 1
N° 1
4
5
3
3
1
2
5
3
8
200 Ø Flue manifold kit for
expansion code: 3.034260
--
N° 1
N° 2
N° 3
6
7
