- Page 1 VICTRIX PRO Instruction booklet and warning 35 - 55 2 ErP Installer User Maintenance Technician...
-
Page 3: Table Of Contents
Checks following conversion to another type of gas..45 1.12 External temperature probe (Optional)......14 3.15 adjustment..............45 1.13 Immergas flue systems............15 3.13 Converting the boiler to other types of gas ....45 1.14 Tables of equivalent length factors........16 3.16 CH output adjustment. -
Page 4: Dear Customer
Dear Customer, Our compliments for having chosen a top-quality Immergas product, able to ensure well-being and safety for a long period of time. As an Immergas customer you can also count on a Qualified Authorised After-Sales Technical Assistance Centre, prepared and updated to guarantee constant efficiency of your boiler. -
Page 5: Safety Symbols Used
SAFETY SYMBOLS USED. GENERIC HAZARD Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situa- tions resulting in possible harm to the health of the operator and user in general. ELECTRICAL HAZARD Strictly follow all of the indications next to the pictogram. -
Page 6: Boiler Installation
ATTENTION: Note: appliance classification is provided in the de- pictions of the various installation solutions shown single installation Victrix Pro 35 2 ErP on the following pages. boilers can be installed outdoors or in Only professionally enabled companies are authorised a domestic use environment or similar accor- to install Immergas gas appliances. - Page 7 ATTENTION: Installation Standards: installation of the Victrix Pro boiler - This boiler can be installed outdoors, when powered by LPG must comply without additional protections. with the rules regarding gases with a greater - Installation of gas appliances, flue exhaust density than air (remember, as an example, pipes and combustion air intake pipes is for- that it is prohibited to install plants powered...
- Page 8 Filling the condensate drain trap. N.B.: wall mounting of the boiler must guarantee stable and efficient support for the boiler. The On first lighting of the boiler, flue gas may plugs (standard supply) are only to be used to fix the come out from the condensate drain;...
-
Page 9: Main Dimensions
MAIN DIMENSIONS. Key: V - Electrical connection G - Gas supply R - System return M - System flow SC - Condensate drain (minimum internal diameter Ø 13 mm) Height Width Depth (mm) (mm) (mm) Connections SYSTEM 3/4” 1”1/2 1”1/2 MINIMUM INSTALLATION DISTANCES. -
Page 10: Position Of The Appliances
S > 775 cm for every Victrix Pro 55 2 ErP conditions. (ex: to install 3 Victrix Pro 35 2 ErP in cascade, the minimum surface is 525 x 3 = 1575 cm Height of the installation room. c) underground rooms at quota between -5 m and -10 m from the Installation of individual appliance: the room must have a mini- reference surface (S ≥... -
Page 11: Outdoor Installation
2 (EN 1717:2002 or local regulations in force). The materials used for the central heating circuit of Immergas the appliance and the gas system. This cock, boilers withstand ethylene and propylene glycol based anti- if supplied by the appliance’s manufacturer,... -
Page 12: Hydraulic Connection
The internal gas supply system must be built in compliance with Water connections must be made in a rational way using the cou- the provisions and regulations and all legislation in force, and plings on the boiler template. The discharge of the boiler safety any other reference on good technique. -
Page 13: Electrical Connection
1.10 ELECTRICAL CONNECTION. The power cable must be laid as shown (Fig. 4). If the network fuse on the connection terminal block needs re- ATTENTION: placing, this must also be done by qualified personnel: use a 3.15A the electrical system must be built in F (quick) 250V fuse (size 5 x 20). -
Page 14: Optional Boiler Controllers
1.11 OPTIONAL BOILER CONTROLLERS. If the cascade and zone regulator is used, it is com- The boiler is prepared for the application of a cascade and zone pulsory to set up separate lines with different power regulator, zone manager and external probe. supply voltages, particularly it is essential to separate the very low voltage connections from the 230 V ones. -
Page 15: Immergas Flue Systems
1.13 IMMERGAS FLUE SYSTEMS. - Type B open chamber boilers must not be installed in places Immergas supplies various solutions separately from the boilers where commercial, artisan or industrial activities take place, regarding the installation of air intake terminals and flue exhaust, which use products that may develop volatile vapours or sub- which are fundamental for boiler operation. -
Page 16: Tables Of Equivalent Length Factors
• Coupling extension pipes and concentric elbows. To install 1.14 TABLES OF EQUIVALENT LENGTH FACTORS. push-fitting extensions with other elements of the flue, proceed Equivalent length in m as follows: Install the concentric pipe or elbow with the male side TYPE OF DUCT of concentric pipe Ø... -
Page 17: Concentric Horizontal Kit Installation
The kit with this configuration can be extended up to a max. with frontal outlet, one must use the fixing plate and a concentric measurement of 8.0 m with Victrix Pro 35 2 ErP and 14.5 m for bend coupling in order to ensure sufficient space to carry out the Victrix Pro 55 2 ErP, including the grid-covered terminal and the tests required by law upon commissioning. -
Page 18: Concentric Vertical Kit Installation
• Maximum length (MAX L) (Fig. 14). The kit with this config- uration can be extended up to a max. measurement of 11.5 m with Victrix Pro 35 2 ErP and 18.0 m with Victrix Pro 55 2 ErP, including the terminal The kit includes: N°... -
Page 19: Installation Of Vertical Terminals 80 Ø
• Maximum length (MAX L) (Fig. 16). The kit with this config- uration can be extended up to a max. measurement of 24.0 m with Victrix Pro 35 2 ErP and 30.0 m with Victrix Pro 55 2 ErP, including the terminal. -
Page 20: Installation Of 80 Ø Horizontal Terminals
24.0 sealing and joining of the elements making up the kit. m with Victrix Pro 35 2 ErP and 30.0 m with Victrix Pro 55 2 ErP, including the terminal. -
Page 21: Flue Duct Systems For Voids And Chimneys
- The max. possible length of the 80 Ø flexible ducting vertical in particular, the declaration of conformity must be compiled at section is equal to 11.0 m for Victrix Pro 35 2 ErP and 15.0 m the end of work and on commissioning of the ducted system. The for Victrix Pro 55 2 ErP. -
Page 22: Condensate Trap Filling
1.22 CONDENSATE TRAP FILLING. 1.25 CIRCULATION PUMP. On first lighting of the boiler combustion products may come out The boilers are supplied with a variable speed circulator pump. the condensate drain; after a few minutes’ operation check that this With boiler in central heating mode, the speed of the circulator no longer occurs. -
Page 23: Kits Available On Request
Pump release. • Ø 80 horizontal kit with flue exhaust. If, after a prolonged period of inactivity, the circulation pump is • 80 Ø horizontal terminal kit with wall flue exhaust. blocked, unscrew the front cap and turn the motor shaft using a •... -
Page 24: Boiler Components
1.27 BOILER COMPONENTS. Key: 1 - P.C.B. 18 - Sample points (air A) - (flue gas F) 2 - Gas valve 19 - Heat exchanger safety thermal fuse 3 - Absolute pressure switch 20 - Manual air vent valve 4 - Gas nozzle 21 - Condensation module 5 - Sleeve with seats for Venturi 22 - Heat-exchanger safety thermostat... -
Page 25: Hydraulic Diagram With Optional
Immergas original kits or uses them im- structions in compliance with the provisions properly. of the "R" collection. Whenever the generators... -
Page 26: Installation Examples Of Individual Boiler
1.29 INSTALLATION EXAMPLES OF INDIVIDUAL BOILER. -
Page 27: Instructions For Use And Maintenance
• Never clean the appliance or connected parts with easily flammable substances. ATTENTION: • Never leave containers or flammable sub- (only cascade Victrix Pro 35 2 ErP and stances in the same environment as the Victrix Pro 55 2 ErP) appliance. -
Page 28: Cleaning And Maintenance
ATTENTION: ATTENTION: The use of components involving use of if you smell burning or see smoke electrical power requires some funda- coming out of the appliance, switch it mental rules to be observed such as: off, disconnect the power, close the main gas - do not touch the appliance with wet or moist cock, open the windows and call an authorised parts of the body;... -
Page 29: Control Panel
2.4 CONTROL PANEL. Key: 14 - Not used 1 - Main switch 15 - Not used 2 - CH temperature adjustment buttons 16 - Parameter adjustment in progress 3 - Sliding door 17 - Boiler in stand-by 4 - DHW temperature adjustment buttons (optional) 18 - External probe connected (optional) 5 - Boiler manometer 19 - Unit of measurement... -
Page 30: Using The Boiler
2.5 USING THE BOILER. You will need to press “B” to save the new value. The temperature Before ignition, make sure that the system is full of water, check- reading will flash during adjustment. If a certain amount of time ing that the manometer (5) indicates a base value at which the lapses without saving the value, the boiler will exit setting mode system has been designed and calculated and however not less... -
Page 31: Fault And Anomaly Signals
To scroll through the list, press buttons + and - (ref. 2 fig. 29). In this mode the boiler is considered powered on but not active. Accordingly, the appliance’s anti-freeze function is guaranteed. To exit the menu, press and hold “C” down again. To turn it back on simply press “B”. - Page 32 Error Anomaly signalled Cause Boiler status /Solution Code In the event of request of room central heating or domestic hot water production, the boiler does not switch on within the preset No ignition block Press the Reset button (1) time. Upon appliance commissioning or after extended downtime, it may be necessary to eliminate the block.
-
Page 33: Info Menu
Error Anomaly signalled Cause Boiler status / Solution Code Check on the boiler pressure gauge (1) that the system pressure is between 1÷1.2 Insufficient system 0E37 If the system flow rate / pressure is too low the boiler switches off. bar and restore the correct pressure if pressure or flow necessary. -
Page 34: Boiler Shutdown
BOILER SHUTDOWN. 2.11 ANTIFREEZE PROTECTION. Disconnect the main switch (1) taking it to the “0” position and The boiler is supplied with an antifreeze function as standard close the gas cock upstream from the appliance. that activates the function of the pump and the burner when the Never leave the boiler switched on if left unused for prolonged system water temperature in the boiler falls below 5°C. -
Page 35: Instructions For Maintenance And Initial Check
With regard to the above, only use Immergas original spare parts when replacing parts. If additional documentation needs to be consulted for extraordinary maintenance, contact the Authorised After-Sales Service. -
Page 36: Yearly Appliance Check And Maintenance
10 seconds. using nylon or broomcorn brushes; it is forbidden to use brushes made of metal or other materials that may damage Victrix Pro 35 2 ErP the combustion chamber. at nominal at minimum... -
Page 37: Hydraulic Diagram
3.4 HYDRAULIC DIAGRAM. Key: 1 - Draining funnel on view 20 - Fumes hood 2 - Boiler draining valve 21 - Heat-exchanger safety thermostat (manual reset) 3 - 4 bar safety valve 22 - Over temperature safety thermostat 4 - Flow manifold 23 - System return regulation probe 5 - Absolute pressure switch 24 - System flow regulation probe... -
Page 38: Circuit Wiring Diagram
230 V CIRCUIT WIRING DIAGRAM. For safety reasons the P.C.B. envisions a fuse that cannot be re- “simple cascade”, or when connecting in “system side flow probe”, stored in series with the electric power supply of the gas valve. or “D.H.W. pump”. Configure the corresponding parameters when connecting in... -
Page 39: Very Low Voltage Wiring Diagram
VERY LOW VOLTAGE WIRING DIAGRAM. Jumper X40 must be removed when the Room thermostat is con- Configure the corresponding parameters when connecting in nected; in addition, it must be eliminated also in case of connection “simple cascade”, or when connecting in “system side flow probe”, to “WE-BUS”, “0-10”, “Simple cascade BUS”, BUS OT. -
Page 40: Pump Boiler And Tank Probe Wiring Diagram (Optional)
D.H.W. PUMP BOILER AND TANK PROBE WIRING DIAGRAM (optional). Key: B1-2 -System flow probe (NTC) (optional) B2 - Domestic hot water probe (NTC) (optional) B4 - External probe (optional) M2 - Plant CH pump (optional) M3 - Domestic hot water pump (optional) Note (probe B1-2, B2, B4): - Connection cable diameter 3÷7 mm - Cable section 0.5 ÷... -
Page 41: Troubleshooting
3.10 TROUBLESHOOTING. - check that the exchanger safety thermostat has not intervened. If it has, check the integrity of the module and ceramic fibre panel, Maintenance interventions must be carried out by an replace the cover gasket of the manifold and reset the thermostat authorised company (for example contact the Author- by pressing the specific button ised Technical Service Centre). -
Page 42: Programming The Boiler P.c.b
3.12 PROGRAMMING THE BOILER P.C.B. - Save the parameters by switching from one parameter to the next The boiler is prepared for possible programming of several op- or by pressing “B”. eration parameters. By modifying these parameters as described below, the boiler can be adapted according to specific needs. - Access programming by pressing and holding down buttons “B”... - Page 43 Programming menu Adjustment Customised Menu item Description Default value range Value P01 CH Set This defines the boiler's flow temperature during heating 20 ÷ P02 °C This defines the maximum settable flow temperature during P02 Max CH Set 20 ÷ 95 °C heating P03 Heating Hysteresis This defines the power-off hysteresis during the heating phase...
- Page 44 Programming menu Adjustment Customised Menu item Description Default value range Value 35 kW Met. 35 kW GPL This defines the max fan speed and therefore the maximum P25 Max fan Speed relative boiler operating power (RPM speed is calculated by P26 ÷...
-
Page 45: Checks Following Conversion To Another Type Of Gas
3.14 CHECKS FOLLOWING CONVERSION TO 3.13 CONVERTING THE BOILER TO OTHER ANOTHER TYPE OF GAS. TYPES OF GAS After making sure that transformation was carried out with the If the boiler has to be converted to a different gas type Venturi and a nozzle of suitable diameter for the type of gas used to that specified on the data plate, request the relative and the calibration has been performed at the correct num. -
Page 46: Output Adjustment
3.16 CH OUTPUT ADJUSTMENT. 3.19 3-WAY PUMP ANTI-BLOCK FUNCTION (OPTIONAL). If it is necessary to change the CH output, you will need to adjust the “P08” maximum CH output and “P09” minimum CH output The boiler has a function that starts the pump and 3-way valve parameters. -
Page 47: Functioning With Common Flow Probe
3.23 FUNCTIONING WITH COMMON FLOW PROBE. 3.25 SIMPLE CASCADE (MAX. 2 BOILERS) With a hydraulic circuit breaker, there must be a common flow It is possible to create a “simple cascade” by directly connecting probe (with boiler flow probe functions) and a pump to be con- two boilers. -
Page 48: Casing Removal
3.26 CASING REMOVAL. - press the two side hooks (7) and tilt the control panel (6); To facilitate boiler maintenance the casing can be completely - remove the lower grid (8) by loosening the 4 screws (9); removed as follows: - at this point, if necessary, you can take down the protective cover - take the two screws out (3) from the bottom of the front (2);... - Page 49 Ref. A Rif. A...
-
Page 50: Technical Data
Burner pressure values refer to use of gas at 15°C. The number of revs for the fan on the display is expressed in revs / 50 (Ex.: 1000 revs = 20). Victrix PRO 35 2 ErP. METHANE (G20) PROPANE (G31) -
Page 51: Combustion Parameters
0.81 1350 0.59 1350 4300 0.58 1100 0.43 1100 COMBUSTION PARAMETERS. Victrix PRO 35 2 ErP Gas nozzle diameter 10.5 Supply pressure mbar (mm H 20 (204) 37 (377) Flue flow rate at nominal heat output kg/h (g/s) 55 (15.28) 56 (15.56) -
Page 52: Technical Data Table
TECHNICAL DATA TABLE. Victrix PRO 35 2 ErP Victrix PRO 55 2 ErP Nominal heat input kW (kcal/h) 34.9 (30051) 51.3 (44098) Minimum heat input kW (kcal/h) 3.9 (3388) 5.5 (4715) Nominal heat output (useful) kW (kcal/h) 34.0 (29240) 49.9 (42914) -
Page 53: Key For Data Nameplate
KEY FOR DATA NAMEPLATE. Cod. Md Sr N° Cod. PIN Type Qnw/Qn min. Qnw/Q max. Pn min. Pn max. Class CONDENSING Note: the technical data is provided on the data nameplate on the boiler Model Code Md Model code Sr N° Serial Number Check Code PIN... -
Page 54: Technical Parameters For Mixed Boilers (In Compliance With Regulation 813/2013)
Contact information IMMERGAS S.p.A. VIA CISA LIGURE, 95 - 42041 BRESCELLO (RE) ITALY (*) High temperature mode means 60°C on return and 80°C on flow. (**) Low temperature mode for condensation Boilers means 30°C , for low temperature boilers 37°C and for other appliances 50°C of return temperature. -
Page 55: Product Fiche (In Compliance With Regulation 811/2013)
For proper installation of the device, refer to chapter 1 of this booklet (for the installer) and current installation regulations. For proper maintenance refer to chapter 3 of this booklet (for the maintenance technician) and adhere to the frequencies and methods set out herein. Victrix Pro 35 2 ErP Victrix Pro 55 2 ErP... -
Page 56: Parameters For Filling In The Package Fiche
PARAMETERS FOR FILLING IN THE PACKAGE The remaining values must be obtained from the technical data FICHE. sheets of the products used to make up the assembly (e.g. solar In case you should wish to install an assembly, starting from the devices, integration heat pumps, temperature controllers). - Page 57 Parameters for filling in the assembly chart. Parameter Victrix Pro 35 2 ErP Victrix Pro 55 2 ErP ‘I’ ‘II’ ‘III’ 0.79 0.53 ‘IV’ 0.31 0.21 * to be established by means of table 5 of Regulation 811/2013 in case of “assembly” including a heat pump to integrate the boiler.
- Page 58 Facsimile for filling in the domestic hot water production system package fiche. Water heating energy efficiency of combination boiler ‘I’ Stated load profile: Solar contribution From the board of the solar device Auxiliary electricity ( 1,1 x ‘I’ 10 % ) ‘II’...
- Page 59 Parameters for filling in the DHW package fiche. Parameter Victrix Pro 35 2 ErP Victrix Pro 55 2 ErP ‘I’ ‘II’ ‘III’ * to be determined according to Regulation 811/2013 and transient calculation methods as per Notice of the European Community no.
- Page 64 Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 Fax 0522.680617 IMMERGAS SPA - ITALY CERTIFIED COMPANY UNI EN ISO 9001:2015 Design, manufacture and post-sale assistance of gas boilers, gas water heaters and related accessories...
