- Page 1 VICTRIX PRO V2 Instructions and warnings IE CASCADE INSTALLATION...
-
Page 2: Table Of Contents
(four mixed and one direct) with domestic hot water storage tank ..........................53 Replacing cascade generators ........................................ 55 Replacing Victrix Pro 35-55 2 ERP and Victrix Pro 35-55 1 E with Victrix Pro V2 35-55 EU ..................56 Replacing Victrix 50 with Victrix Pro V2 55 EU ................................56 Replacing Victrix 68 2 ERP and Victrix Pro 68 1 E with Victrix Pro V2 68 EU ...................... -
Page 3: Installation Recommendations
Law. The appliances must be installed in the configurations and with their original Immergas battery kits. Immergas S.p.a. declines all liability whenever the installation tech- nician does not use Immergas original appliances and kits or uses them improperly. -
Page 4: Definition Of Cascade
Also, based on the installed output, it is necessary to correctly install the flue system. The following tables provide the parameters to correctly set up the boilers and flue system. VICTRIX PRO V2 35 EU 2 Victrix Pro V2 35 EU 3 Victrix Pro V2 35 EU 4 Victrix Pro V2 35 EU... -
Page 5: Anti-Humidity
Victrix Pro V2 150 EU 2 Victrix Pro V2 150 EU 3 Victrix Pro V2 150 EU 4 Victrix Pro V2 150 EU 5 Victrix Pro V2 150 EU Nominal heat input (kW) 282.0 423.0 564.0 705.0 Flue diameter (mm) Ø... -
Page 6: Installation Clearances Victrix Pro V2 35-55-60-68-80 Eu
2.2 INSTALLATION CLEARANCES VICTRIX PRO V2 35-55-60-68-80 EU... -
Page 7: Installation Clearances Victrix Pro V2 100-120 Eu
2.3 INSTALLATION CLEARANCES VICTRIX PRO V2 100-120 EU... -
Page 8: Installation Clearances Victrix Pro V2 150 Eu
2.4 INSTALLATION CLEARANCES VICTRIX PRO V2 150 EU... -
Page 9: Installation Clearance Victrix Pro V2 180 Eu
2.5 INSTALLATION CLEARANCE VICTRIX PRO V2 180 EU... -
Page 10: Installation Of Hydraulic Manifold Kits
Before closing the system shut-off valves, the boiler must be switched off. VICTRIX PRO V2 boilers have an electrical insulation rating of IPX5D. However, if installed outdoors, it is advisable to insulate the relative pipes and protect the kits from the weather. - Page 11 LEFT OUTLET RIGHT OUTLET Key: 17 - Lower protecting plate 18 - Generator M - System flow R - System return...
-
Page 12: Victrix Pro V2 35-55-60-68-80 Eu Additional Boiler Hydraulic Manifold Kit Installation
3.2 VICTRIX PRO V2 35-55-60-68-80 EU ADDITIONAL BOILER HYDRAULIC MANIFOLD KIT INSTALLATION Remove the lower protecting plate (15) of the boiler (16). Pre-mount the fitting unit (12) and nipples (7) on the 3-way valve (11), interposing suitable sealing material such as oakum or similar. - Page 13 Key: 15 - Lower protecting plate 16 - Generator M - System flow R - System return...
-
Page 14: Installation Of Hydraulic Manifold Kit 2 Boilers In Series Victrix Pro V2 100-120-150 Eu
Before closing the system shut-off valves, the boiler must be switched off. VICTRIX PRO V2 boilers have an electrical insulation rating of IPX5D. However, if installed outdoors, it is advisable to insulate the relative pipes and protect the kits from the weather. - Page 15 LEFT OUTLET RIGHT OUTLET Key: 20 - Lower protecting plate 21 - Generator M - System flow R - System return...
-
Page 16: Victrix Pro V2 100-120-150 Eu Additional Boiler Hydraulic Manifold Kit Installation
3.4 VICTRIX PRO V2 100-120-150 EU ADDITIONAL BOILER HYDRAULIC MANIFOLD KIT INSTALLATION Remove the lower protecting plate (18) of the boiler (19). Pre-mount the fitting unit (15) and nipples (10) on the 3-way valve (14), interposing suitable sealing material such as oakum or similar. - Page 17 1902 Key: 18 - Lower protecting plate 19 - Generator M - System flow R - System return...
-
Page 18: Installation Of Hydraulic Manifold Kit 2 Boilers In Series Victrix Pro V2 180 Eu
Before closing the system shut-off valves, the boiler must be switched off. VICTRIX PRO V2 boilers have an electrical insulation rating of IPX5D. However, if installed outdoors, it is advisable to insulate the relative pipes and protect the kits from the weather. - Page 19 LEFT OUTLET RIGHT OUTLET Key: 20 - Lower protecting plate 21 - Generator M - System flow R - System return...
-
Page 20: Victrix Pro V2 180 Eu Additional Boiler Hydraulic Manifold Kit Installation
VICTRIX PRO V2 180 EU ADDITIONAL BOILER HYDRAULIC MANIFOLD KIT INSTALLATION Remove the lower protecting plate (18) of the boiler (19). Pre-mount the fitting unit (15) and nipples (10) on the 3-way valve (14), interposing suitable sealing material such as oakum or similar. - Page 21 2443 Key: 18 - Lower protecting plate 19 - Generator M - System flow R - System return...
-
Page 22: Flue Installation
The “green series” manifold cannot be installed externally without suitable protection against UV rays and other effects of the weather. For the Victrix Pro V2 180 EU model, cascade fume exhaust is not provided. 4.2 FLUE EXHAUST MANIFOLD KIT ASSEMBLY Replace the intake closing cap on the boiler with the intake stub kit (1). -
Page 23: Assembly Of Additional Boiler Manifold Kit For Victrix Pro V2 35-55-60-68-80 Eu
4.3 ASSEMBLY OF ADDITIONAL BOILER MANIFOLD KIT FOR VICTRIX PRO V2 35-55-60-68-80 EU The extension kits make it possible to complete cascade installation, and you must have one for each boiler being connected, according to figure 20 (max of 5 boilers in cascade). -
Page 24: Assembly Of Additional Boiler Manifold Kit For Victrix Pro V2 100-120 Eu
4.4 ASSEMBLY OF ADDITIONAL BOILER MANIFOLD KIT FOR VICTRIX PRO V2 100-120 EU The extension kits make it possible to complete cascade installation, and you must have one for each boiler being connected, according to figure 21 (max of 5 boilers in cascade). -
Page 25: Assembly Of Additional Boiler Manifold Kit For Victrix Pro V2 150 Eu
Manifold kit composition Ø 200 Victrix Pro V2 150 EU additional boiler Ref. Description Boiler connection DN110-125 Clapet DN125 Manifold DN200 Manifold kit composition Ø 250 additional boiler for Victrix Pro V2 150 EU (boiler no. 4) Ref. Description Boiler connection DN110-125 (4th boiler) Clapet DN125 Manifold DN200-250 (4th boiler) Manifold kit composition Ø... -
Page 26: Cascade Electrical Connections
CASCADE ELECTRICAL CONNECTIONS The cascade can be managed via communication BUS (cascade and zone regulator and simple cascade) as shown in the diagrams below. 5.1 SIMPLE CASCADE By connecting several appliances via BUS (already available on individual appliances), a simple cascade can be created. Each request alternates the sequence in which the appliances are ignited. -
Page 27: Auto-Detection
• Re-configuring an appliance as single If a Master or Slave appliance is to be switched back to a single appliance, follow the procedure outlined in section 5.2. The single unit is still referred to as Master. After configuring the appliance as an individual, it may be necessary to modify those previously customised parameters and then return them to their initial conditions. -
Page 28: Restore Settings And Parameter Synchronisation
• Single appliance configuration If you want to revert to single appliance configuration, you must switch off all other appliances and then repeat the auto-detection procedure, making sure to set it as Master. In this case, the total number of recognised appliances must be equal to 1 (recognition correctly as a single appliance). Once the appliance has been configured as a single appliance, the Reset Settings function can help to reset many parameters previously modified from Simple Cascade to default values If one or more Simple Cascade appliances have been configured as single, it is assumed that the Simple Cascade communication BUS is removed for their... -
Page 29: Cascade Technician Menu (Master)
5.5 CASCADE TECHNICIAN MENU (MASTER) To access the technician menu, enter the password '123' using the '+' and '-' buttons, pressing 'OK' with each digit entered. For the menus in the Master appliance, see the boiler manual, with the exception of the cascade menu, which is explained in more detail below. TECHNICIAN/Cascade Menu Settings Single burner power... -
Page 30: Technician Menu (Slave)
TECHNICIAN/Cascade/Automatic detection Menu The function called up by this parameter is used to detect the number of appliances in cascade. This function can also be used to set a Master or Slave appliance as a single appliance. See section 'Auto-detection' for more details. TECHNICIAN/Cascade/Parameter synchronisation menu WARNING: read and understand what is stated in the "Parameter Synchronisation"... - Page 31 TECHNICIAN/System settings/Fan parameters menu Menu item Description Range Default Synchronisation Customised value See boiler manual and To set the speed used during burner 750 - 6750 Ignition speed * table chapter ignition. (rpm) 2 of this manual Minimum speed This defines the max fan speed and See boiler Maximum speed ** therefore the maximum relative boiler...
- Page 32 TECHNICIAN/System settings/Decreasing slope menu Menu item Description Range Default Synchronisation Customised value The decreasing slope is a power value that 0 - 100 See boiler Power threshold triggers the protection. Below this value, the booklet boiler output is reduced by 1% per time period Defines the Time [0.2s] for a step during the 0 - 255 See boiler...
- Page 33 TECHNICIAN/Diagnostics/System Information menu Menu item Description Flame current * Value in µA. Actual fan speed Real-time fan speed (rpm). Required fan speed Fan setpoint (rom). Modulation level * Effective burner output value (%). Boiler setpoint * Temperature value calculated by the system (°C) **. CH setpoint * Required temperature value during heating (°C) **.
-
Page 34: User Menu (Slave)
TECHNICIAN/Cascade/Automatic detection Menu The function called up by this parameter is used to set the role of the Slave appliance in cascade, although normally this menu is opened automatically by activat- ing this function from Master. This function can also be used to set a Master or Slave appliance as a single appliance. See section 'Auto-detection' for more details. -
Page 35: Installation Diagram Victrix Pro V2 In Simple Cascade Two Direct Heating Zones With Dhw Tank
5.8 INSTALLATION DIAGRAM VICTRIX PRO V2 IN SIMPLE CASCADE TWO DIRECT HEATING ZONES WITH DHW TANK... -
Page 36: Installation Diagram Victrix Pro V2 In Simple Cascade One Direct Central Heating Zone And One Mixed Heating Zone With Domestic Hot Water Boiler
5.9 INSTALLATION DIAGRAM VICTRIX PRO V2 IN SIMPLE CASCADE ONE DIRECT CENTRAL HEATING ZONE AND ONE MIXED HEATING ZONE WITH DOMESTIC HOT WATER BOILER... -
Page 37: Tables And Notes Common To Simple Cascade Wiring Diagrams
5.10 TABLES AND NOTES COMMON TO SIMPLE CASCADE WIRING DIAGRAMS The tables and notes in this paragraph apply to the diagrams in Fig. 25-26-27-28-29-30-31-32. • Type and size of connecting cables ELECTRICAL CONNECTIONS (SIGNALS) Cable gauge (mm Components Cable diameter (mm) Maximum length (m) minimum maximum... -
Page 38: Wiring Diagram Two Heating Zones (Direct + Mixed) And Dhw Pump
5.11 WIRING DIAGRAM TWO HEATING ZONES (DIRECT + MIXED) AND DHW PUMP... -
Page 39: Wiring Diagram Zone 1 Mixed Heating And Dhw Pump
5.12 WIRING DIAGRAM ZONE 1 MIXED HEATING AND DHW PUMP... -
Page 40: Wiring Diagram Two Direct Heating Zones And Dhw Pump - Opentherm
5.13 WIRING DIAGRAM TWO DIRECT HEATING ZONES AND DHW PUMP - OPENTHERM... -
Page 41: Wiring Diagram Two Direct Heating Zones And Dhw Pump - Only Outdoor Temperature Climate Curve
5.14 WIRING DIAGRAM TWO DIRECT HEATING ZONES AND DHW PUMP - ONLY OUTDOOR TEMPERATURE CLIMATE CURVE... -
Page 42: Wiring Diagram Two Direct Heating Zones And Dhw Pump - Constant Setpoint
5.15 WIRING DIAGRAM TWO DIRECT HEATING ZONES AND DHW PUMP - CONSTANT SETPOINT... -
Page 43: Wiring Diagram Direct Heating Zone And Dhw Pump
5.16 WIRING DIAGRAM DIRECT HEATING ZONE AND DHW PUMP... -
Page 44: Wiring Diagram Direct Heating Zone And Dhw Pump - Parallel Operation
5.17 WIRING DIAGRAM DIRECT HEATING ZONE AND DHW PUMP - PARALLEL OPERATION... -
Page 45: Wiring Diagram Two Hydraulic Zones With System Heating Pump
5.18 WIRING DIAGRAM TWO HYDRAULIC ZONES WITH SYSTEM HEATING PUMP... -
Page 46: Simple Cascade Bus Connection Wiring Diagram
5.19 SIMPLE CASCADE BUS CONNECTION WIRING DIAGRAM ≤ 2 m ≤ 2 m... -
Page 47: Wiring Diagram Connection To Bms (Simple Cascade)
5.20 WIRING DIAGRAM CONNECTION TO BMS (SIMPLE CASCADE) ≤ 2 m... -
Page 48: Cascade And Zone Regulator
CASCADE AND ZONE REGULATOR 6.1 CASCADE INSTALLATION DIAGRAM... - Page 49 Togliere tensione all’apparecchio prima di effettuare ogni collegamento elettrico. Cut off the power to the appliance before setting up any electrical connection. The communication board (4) is an accessory supplied as an option. Set the address on the communication board (4) of each individual boiler according to the indications (fig. 37); we recommend starting with address '0'. After removing the front casing (the operation of which is indicated in the boiler manual in the Maintenance section), open the front panel (1) (making sure beforehand that the power to the boiler has been switched off) by pressing on the top of the control panel near the two hooks;...
-
Page 50: Wiring Diagram With Old Cascade Regulator (3.015244) - Three Heating Zones (Two Mixed And One Direct) With Domestic Hot Water Storage Tank
The external probe can be connected to the lower-address appliance as an - Zone 2 temperature probe (PTC) alternative to connection to the Cascade and Zone Regulator (order the Immergas - External probe (PTC) code for the appropriate external probe). -
Page 51: Wiring Diagram With Cascade Regulator And Vpv2 Zones (3.034119) - Three Heating Zones (Two Mixed And One Direct) With Domestic Hot Water Storage Tank
6.3 WIRING DIAGRAM WITH CASCADE REGULATOR AND VPV2 ZONES (3.034119) - THREE HEATING ZONES (TWO MIXED AND ONE DIRECT) WITH DOMESTIC HOT WATER STORAGE TANK... - Page 52 Probe cable gauge: 0.5 mm Maximum permitted length: 100 m (2 x 100 m). The external probe can be connected to the lower-address appliance as an alternative to connection to the Cascade and Zone Regulator (order the Immergas code for the appropriate external probe).
-
Page 53: Wiring Diagram With Cascade Regulator And Vpv2 Zones (3.034119) - Five Heating Zones (Four Mixed And One Direct) With Domestic Hot Water Storage Tank
6.4 WIRING DIAGRAM WITH CASCADE REGULATOR AND VPV2 ZONES (3.034119) - FIVE HEATING ZONES (FOUR MIXED AND ONE DIRECT) WITH DOMESTIC HOT WATER STORAGE TANK... - Page 54 Probe cable gauge: 0.5 mm Maximum permitted length: 100 m (2 x 100 m). The external probe can be connected to the lower-address appliance as an alternative to connection to the Cascade and Zone Regulator (order the Immergas code for the appropriate external probe).
-
Page 55: Replacing Cascade Generators
The thermal module 'Victrix Pro V2 35 EU' is compatible for replacing modules 'Victrix Pro 35 2 ErP' and 'Victrix Pro 35 1 E'. The Victrix 50, Victrix Pro 55 2 ErP and Victrix Pro 55 1 E thermal module can be replaced with an equivalent IMMERGAS thermal module with the following... -
Page 56: Replacing Victrix Pro 35-55 2 Erp And Victrix Pro 35-55 1 E With Victrix Pro V2 35-55 Eu
7.1 REPLACING VICTRIX PRO 35-55 2 ERP AND VICTRIX PRO 35-55 1 E WITH VICTRIX PRO V2 35-55 EU Key: 1 - Victrix Pro V2 35-55 EU 3 - Battery hydraulic manifold kit 2 - Victrix Pro 35-55 2 ERP and Victrix Pro 35-55 1 E 7.2 REPLACING VICTRIX 50 WITH VICTRIX PRO V2 55 EU... -
Page 57: Replacing Victrix 68 2 Erp And Victrix Pro 68 1 E With Victrix Pro V2 68 Eu
7.3 REPLACING VICTRIX 68 2 ERP AND VICTRIX PRO 68 1 E WITH VICTRIX PRO V2 68 EU Key: 1 - Victrix Pro V2 68 EU 3 - Victrix Pro Adapter Kit 2 - Victrix 68 2 ERP and Victrix Pro 68 1 E 4 - Battery hydraulic manifold kit 7.4 REPLACING VICTRIX 75 WITH VICTRIX PRO V2 80 EU... -
Page 58: Replacing Victrix Pro 80 2 Erp And Victrix Pro 80 1 E With Victrix Pro V2 80 Eu
7.5 REPLACING VICTRIX PRO 80 2 ERP AND VICTRIX PRO 80 1 E WITH VICTRIX PRO V2 80 EU Key: 1 - Victrix Pro V2 80 EU 3 - Victrix Pro Adapter Kit 2 - Victrix Pro 80 2 ERP and Victrix Pro 80 1 E 4 - Battery hydraulic manifold kit 7.6 REPLACING VICTRIX 90-115 WITH VICTRIX PRO V2 100-120 EU... -
Page 59: Replacing Victrix Pro 100-120 2 Erp And Victrix Pro 100-120 1 E With Victrix Pro V2 100-120 Eu
7.7 REPLACING VICTRIX PRO 100-120 2 ERP AND VICTRIX PRO 100-120 1 E WITH VICTRIX PRO V2 100-120 EU Ø 100 Ø 80 Key: 1 - Victrix Pro V2 100-120 EU 3 - Battery hydraulic manifolds kit 2 - Victrix Pro 100-120 2 ERP and Victrix Pro 100-120 1 E... - Page 60 This instruction booklet is made of ecological paper immergas.com Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 Fax 0522.680617 QUALITY SYSTEM CERTIFIED UNI EN ISO 9001:2015 Design, manufacture and after-sales assistance of gas boilers, gas water heaters and relative accessories...
