VICTRIX PRO V2 EU is the new range of wall-hung condensing
boilers for room heating only, set-up for independent function-
ing and for set configuration (up to 5 appliances with a single
safety devices kit), with the advantage of guaranteeing higher
overall output and reduced running costs. All models can be
installed both inside and outside, on the wall, on a bearing frame
or inside specific technical cabinets. This gives the designer and
installer a variety of solutions to adapt the technological systems
according to the building context.
The high heat output extension of VICTRIX PRO V2 EU is
ideal for central heating with large domestic systems (duplexes,
three-unit houses, condominiums), as well as commercial and
industrial applications.
The new combustion system connected to the boiler's electronics
provides a broader range of output modulation, between 10%
and 100%, therefore streamlining boiler operation, also through
reduced heat load requests (for example during spring and
autumn or when the system is only partially used). Designed
to operate with new gas mixtures (methane + 20% hydrogen)
further reducing atmospheric pollution.
The ecological burners guarantee particularly reduced polluting
emissions (the boilers belong to the most environment-friendly
class envisioned by European Standards - class 6).
The new low consumption modulating pumps change their
speed to check ∆T between the flow and return and, conse-
quently, reduce power consumption and guarantee total silence
during operation.
With single boiler installation, an external 3-way valve can be
connected for coupling to a separate storage tank unit (such as
2
VICTRIX PRO V2 EU
Immergas 300, 500, 1000, 1500 and 2000 litre storage tank
unit).
When operating in set configuration, even exploiting simple
cascade without using the cascade and zone regulator kit, it
is possible to hydraulically couple up to 5 appliances with a
single safety device kit, making it extremely easy to provide
the required output size for the specific heat system.
A wide range of optional hydraulic kits, flue systems, temper-
ature control and accessories are also available to tackle many
practical situations, promoting the sales proposal.
VICTRIX PRO V2 EU (with the exception of mod. 180) can
also be installed on a specific modular supporting frame which
offers single or set installation (up to 5 modules), in linear
set-up, or back-to-back for more limited spaces. The frame
has supporting collars for the hydraulic manifolds and can be
attached to the wall or floor with plugs. Thanks to a specific
surface treatment, the support frame is also type-approved for
outdoor installation, open-air. It can also be installed inside a
containment cabinet kit suitable for outdoor open-air instal-
lation, again with the exception of VICTRIX PRO V2 180 EU,
coupled to specific optional kits.
By purchasing more cabinets, it is also possible to develop set
configurations up to 5-generators.
