VICTRIX PRO V2 100 - 120 - 150 EU
2.1
VICTRIX PRO V2 100 - 120 - 150 EU SPECIFICATIONS
Wall-hung, sealed-chamber and fan-assisted pre-mixed con-
densing modules, high efficiency with forced circulation, with
variable useful power outputs:
VICTRIX PRO V2 100 EU = 90,9 kW - 9,8 kW;
VICTRIX PRO V2 120 EU = 112,3 kW - 11,3 kW;
VICTRIX PRO V2 150 EU = 138,3 kW - 28,3 kW;
and seasonal efficiency ηs 94% (with the exclusion of VICTRIX
PRO V2 150 EU). They can reach ηs 98%, if coupled with
Modulating remote control code 3.020358.
The generators are type-approved for installation both in
heating control unit and outside the building (with specific
protection for open-air installation), can be used in the fol-
lowing configurations:
Standard sealed chamber and fan assisted (appliance type
C
/C
) - Using the vertical or horizontal concentric and
13
33
split kits.
Open chamber and fan assisted (appliance type B
B
) - Specific optional intake stub pipe kit required.
53p
The module consists of:
• total pre-mixing combustion system with steel multigas
cylindrical burner, complete with ignition electrodes and
ionisation control;
• pneumatic gas valve with double shutter;
• primary gas/water heat exchanger with casing in stainless
steel with air vent valve and internal stainless steel coil,
consisting of 12 elements (8+4 flue side - VICTRIX PRO V2
100 EU), of 15 elements (10+5 flue side - VICTRIX PRO V2
120 EU), of 18 elements (12+6 flue side - VICTRIX PRO V2
150 EU);
• combustion chamber in stainless steel internally insulated
using ceramic panels;
• fan for flue evacuation with electronically variable speed;
• circuit for disposal of condensate including trap and flexible
drain hose;
• hydraulic unit composed of a flow manifold, primary circuit
pressure transducer, modulating circulation pump and low
power consumption;
• 5,4 bar system safety valve and standard draining funnel;
• water overheating safety thermostat, heat exchanger safety
thermofuse and heat exchanger safety thermostat (manual
reset);
• flue control probe
• control panel supplied with P.C.B. with microprocessor with
continuous flame modulation on heating with P.I.D. control,
modulation range 1-10 (with the exclusion of mod. 150);
• system flow regulation probe;
• system return regulation probe;
• heating flow temperature with factory setting between 20
and 85°C;
• ignition delay device in central heating phase, antifreeze
protection, pump anti-blocking function, chimney sweep
function;
• control panel composed of main switch, C.H. system pressure
gauge, multifunction back-lit display and 12-key push button
panel with protective sliding door;
• key setting of all functions, including antilegionella function
if coupled with remote DHW storage tank with probe;
• self-diagnosis system with digital display of the temperature,
functioning status and error codes;
• IPX5D electrical insulation level, with possibility of installa-
tion outside with additional cover (open-air);
• antifreeze protection to -5 °C as per standard (-15 °C with
relevant kit optional);
• set-up for the connection of the cascade and zone regulator
kit and of the external probe;
• set-up for connection to an external 3-way valve with 230
Vac power supply, for coupling to a separate storage tank
unit for the production of DHW;
• set-up for functioning in set configuration (up to 5 boilers
with a unique INAIL safety devices kit);
• set-up for the installation of the INAIL-approved safety stub
/ B
/
pipes, both in single and set configuration (up to 5 boilers);
23p
33
• possibility of installation with the supporting frame kit in
"free standing" mode, which can be used to install one or
more VICTRIX PRO V2 EU units. The frame is also suitable
for outdoor open-air installation;
• possibility of installation of the generator within a cabinet
suitable for outdoor installation;
• possibility of connecting (in combination with a cascade and
zone regulator) to a remote management system for remote
management of the system (optional);
Supplied with sample points for combustion analysis, bottom
protective metal-sheet plate and gas interception cock.
Category II appliance
CE Marking.
It is available in the following models:
• VICTRIX PRO V2 100 EU
• VICTRIX PRO V2 120 EU
• VICTRIX PRO V2 150 EU
NOTA BENE: for correct installation of the boiler the Immergas
''Green Range'' air intake/fumes exhaust kit must be used,
dedicated for the VICTRIX PRO V2 EU boiler, whether in
single or cascade (set) configuration.
, operates with natural gas and L.P.G.
2H3P
code: 3.033861
code: 3.033862
code: 3.033863
5
