Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
Page 5
⑯ ⑮ With differential With differential pressure switch pressure indiator ① cover ⑤④ ⑭ ② main body ① ③ case ⑦ 2×Rc ④ hexagon socket head cap screw ⑤ washer ⑥ guide ⑫② ⑦ “O”ring ⑧ packing INLET INLET ⑨ “O”ring ⑩...
Page 6
1. Prior to the installation, confirm the direction of the INLET(2 places)and it should be installed to house the case ③ in the oil tank. 2. When the filter is placed on the oil tank, confirm the“O”ring ⑦ is fitted to the main body ②. 3.
Page 7
G1/2 To be connected to alarm Cord Connector Micro switch Fig. 2 Example of NO (Normally Opened) Connection While operation, when the differential pressure is built up by 0.18MPa or (red colored) indication ring of differential pressure indicator comes up to the sight dome, else when electric signal is sent by differential pressure switch, stop the operation and disassemble by following steps to replace the element ;...
