Doc.no.DOC1075629
PRODUCT NAME
Oil Filter
MODEL / Series / Product Number
FH150 series

Advertisement

loading
Need help?

Need help?

Do you have a question about the FH150 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMC Networks FH150 Series

  • Page 1 Doc.no.DOC1075629 PRODUCT NAME Oil Filter MODEL / Series / Product Number FH150 series...
  • Page 2 Contents ●Safety Instructions P2~P3 1. Specifications 2. Construction 3. Mounting and operation 4. Maintenance...
  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4: Limited Warranty And Disclaimer/Compliance Requirements

    Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 Fluid Hydraulic fluid Operating pressure Max 1.0MPa Operating temperature Max 80 Nominal filtration rating 5, 10, 20μm Rated flow range 5 L/min 10 L/min 20 L/min Port size Rc1/4 Rc3/8 Rc1/2 Operating (differential) pressure for differential pressure indicator 0.13MPa and switch Cover Aluminum die cast Main...
  • Page 6 ① Cover ② Clamp ring ③ Case ④ O-ring ⑤ Element ⑥ Spring ⑦ Label ⑧ Blanking cap ⑨ Differential pressure indicator ⑩ Differential pressure switch ⑪ Bracket...
  • Page 7 1. Check the position of the inlet and outlet before mounting and mount with the bowl ⑤ downwards. 2. If the product is flushed after mounting, be sure to replace the element before starting to run. 3. Ensure there is no leakage at any sealing part before starting to run. 【1】Handling of accessories (differential pressure indicators) 1.
  • Page 8 When the differential pressure reaches 0.13MPa in operation or the ring (red) of the differential pressure floats and shows up entirely at the sight glass, or the differential pressure switch generates an electric signal, stop operation, disassemble the product in the following manner and replace the element. Also, note that the differential pressure indicator tends to operate due to the increased viscosity of the hydraulic fluid in winter, so wait until the hydraulic fluid is heated to 20 to 40oC, and check whether the product is really clogged.
  • Page 9 Revision history 1st edition:March 2024 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
