TO PREVENT POSSIBLE TIPPING, BOLT THIS UNIT TO THE
EXERCISE FLOOR USING MINIMUM 4-1/2" LONG BOLTS. FAILURE
TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH.
Note: Both Serial Number and Model Number are Required when Ordering Parts
Note: Both Serial Number and Model Number are Required when Ordering Parts
Note: Both Serial Number and Model Number are Required when Ordering Parts
Note: Both Serial Number and Model Number are Required when Ordering Parts
RECORD SERIAL NUMBER HERE
RECORD SERIAL NUMBER HERE
RECORD SERIAL NUMBER HERE
RECORD SERIAL NUMBER HERE
MACHINE CODE
MACHINE CODE
MACHINE CODE
MACHINE CODE
A04
A04
A04
A04
RS-2402
LEG CURL
**WARNING!**
Customer Service
Customer Service
Customer Service
Customer Service
(800) 548-5438
(800) 548-5438
(800) 548-5438
(800) 548-5438
(858) 578-7676
(858) 578-7676
(858) 578-7676
(858) 578-7676
Fax
Fax
Fax
Fax
(858) 578-9558
(858) 578-9558
(858) 578-9558
(858) 578-9558
Advertisement
Table of Contents
Related Manuals for Hoist Fitness RS-2402
Summary of Contents for Hoist Fitness RS-2402
- Page 1 RS-2402 LEG CURL **WARNING!** TO PREVENT POSSIBLE TIPPING, BOLT THIS UNIT TO THE EXERCISE FLOOR USING MINIMUM 4-1/2" LONG BOLTS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. Note: Both Serial Number and Model Number are Required when Ordering Parts...
-
Page 2: Table Of Contents
OWNER'S MANUAL OWNER'S MANUAL CONTENTS INSTRUCTIONS ..............FRAME ASSEMBLY .............. PRE-ASSEMBLY..............DECAL PLACEMENT............. DECAL REFERENCE............. PART LIST................ABBREVIATIONS..............BOLT SIZING CHART............WASHER SIZING CHART............MAINTENANCE SCHEDULE..........GENERAL MAINTENANCE INFORMATION......WEIGHT TRAINING TIPS............EXERCISE LOG..............LIMITED WARRANTY............PAGE 01 RS-2402 ASSEMBLY... -
Page 3: Instructions
Be sure to have your serial number and this manual when calling. When all parts have been accounted for, continue on. TOOLS REQUIRED Ratchet Wrench 1/2", 9/16" and 3/4" Sockets Adjustable Wrench Rubber Mallet Tape Measure Level SAE Hex Key Wrench Set Two People RS-2402 ASSEMBLY PAGE 02... - Page 4 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL ***THIS PAGE WAS INTENTIONALLY LEFT BLANK*** PAGE 03 RS-2402 ASSEMBLY...
-
Page 5: Frame Assembly
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY RS-2402 ASSEMBLY PAGE 04... - Page 6 IF YOU PURCHASED AN OPTIONAL ADD ON WEIGHT OPTIONAL ADD ON WEIGHT SYSTEM, ENSURE THE USE SYSTEM, ENSURE THE USE OF RS-CAGE-NG-OPT1 OF RS-CAGE-NG-OPT1 NOTE: RETURN TO RS-CAGE-NG MANUAL TO FINISH WEIGHT CAGE ASSEMBLY 157 1/8" 3991 PAGE 05 RS-2402 ASSEMBLY...
- Page 7 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - HAND TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 06...
- Page 8 - HAND TIGHTEN HARDWARE. NOTE: - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. REPEAT PROCEDURE FOR ALIGN TO ENSURE TAB ALL OTHER INSTANCES (42). IS SECURE IN NOTCH. ALIGN SHAFT (35) WITH ROTATION LOCK (42) AS SHOWN. PAGE 07 RS-2402 ASSEMBLY...
- Page 9 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - HAND TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 08...
- Page 10 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. CABLE PROFILE VIEW NOTE: BE SURE CABLE RUNS BETWEEN THE PULLEYS AND GUARD PINS AS SHOWN. FROM WEIGHT STACK PAGE 09 RS-2402 ASSEMBLY...
- Page 11 AT THE SAME TIME. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. NOTE: BE SURE CABLE RUNS BETWEEN THE PULLEY AND GUARD PIN AS SHOWN. NOTE: BE SURE CABLE RUNS BETWEEN THE PULLEY AND GUARD PIN AS SHOWN. RS-2402 ASSEMBLY PAGE 10...
- Page 12 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - HAND TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 11 RS-2402 ASSEMBLY...
- Page 13 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - HAND TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 12...
- Page 14 OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE (66) & (67) THEN LOOSEN NUT JUST ENOUGH FOR (55) TO PIVOT FREELY. - HAND TIGHTEN ALL OTHER HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 13 RS-2402 ASSEMBLY...
- Page 15 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - HAND TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 14...
- Page 16 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 15 RS-2402 ASSEMBLY...
- Page 17 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE (71). - HAND TIGHTEN ALL OTHER HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 16...
- Page 18 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE (71). - HAND TIGHTEN ALL OTHER HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 17 RS-2402 ASSEMBLY...
- Page 19 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 18...
- Page 20 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. PAGE 19 RS-2402 ASSEMBLY...
- Page 21 OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. RS-2402 ASSEMBLY PAGE 20...
- Page 22 PLEASE SEE RS-CAGE-NG MANUAL FOR FINAL ASSEMBLY. *IMPORTANT* NOW THAT THE RS-2402 IS COMPLETELY ASSEMBLED TAKE TIME TO ASSURE THAT YOUR UNIT IS ASSEMBLED SQUARE AND PERPENDICULAR. IF NOT, IT WILL BE NECESSARY TO LOOSEN SOME FRAME HARDWARE TO RE-ALIGN THE FRAME AND RETIGHTEN BOLTS.
-
Page 23: Pre-Assembly
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL PRE-ASSEMBLY RS-2402 ASSEMBLY PAGE 22... -
Page 24: Decal Placement
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL DECAL PLACEMENT NOTE: - ALL DECALS ARE CENTERED UNLESS OTHERWISE STATED. - SOME PARTS MAY HAVE BEEN REMOVED FOR CLARITY. PAGE 23 RS-2402 ASSEMBLY... -
Page 25: Decal Reference
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL DECAL REFERENCE 021-0013341 021-0003418 021-0003113 021-0004263 SERIAL # DECAL 021-0003421 RS-2402 ASSEMBLY PAGE 24... -
Page 26: Part List
OWNER'S MANUAL PART LIST NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED ITEM NO. PART NUMBER DESCRIPTION QTY. 010-01C0461 CABLE ASSEMBLY RS-2402 - 157 1/8" LG. 022-01PD2049-A SEAT PAD ASSEMBLY 022-01PD2114-A-M BACK PAD ASSEMBLY 022-01PD2119 PAD, LONG ROLLER 026-01X2487 CROSS MEMBER ASSEMBLY... - Page 27 011-0701004 5/16"-18UNC X 1.25" BHCS (Ni) 011-0701003 5/16"-18UNC X 1.00" BHCS (Ni) 011-0116175 5/16"-18UNC X 1.25" LOW HEAD SHCS (Ni) 011-0116186 5/16"-18UNC X 4.00" LOW HEAD SHCS (Ni) 011-0702020 3/8"-16UNC X 1.00" FHCS (Ni) W/NYLON PATCH RS-2402 ASSEMBLY PAGE 26...
- Page 28 DECAL ROM 1-7 021-0003418 DECAL PIVOT POINT (ROUND) 021-0004263 RS WEIGHT STACK DECAL - 270LBS 021-0013341 RS-2402 PLACARD SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" RS-CAGE-NG RS WEIGHT CAGE NG WT-STK #25 30LB TOP WEIGHT ASSEMBLY W/ 10 - 10LB PLATES & 7 - 20LB PLATES...
-
Page 29: Abbreviations
HHB = Hex Head Bolt FHCS = Flat Head Cap Screw BHCS = Button Head Cap Screw SHCS = Socket Head Cap Screw Low Head SHCS = Low Head Socket Head Cap Screw SHSS = Socket Head Shoulder Screw RS-2402 ASSEMBLY PAGE 28... -
Page 30: Bolt Sizing Chart
RECOMMENDED RECOMMENDED RECOMMENDED TORQUE RANGE: TORQUE RANGE: TORQUE RANGE: 47-65 ft-lbs 5-7 ft-lbs 19-26 ft-lbs 3/8" SHSS 5/16" SHSS 1/4" SHSS RECOMMENDED RECOMMENDED RECOMMENDED TORQUE RANGE: TORQUE RANGE: TORQUE RANGE: 17-22 ft-lbs 8-10 ft-lbs 3-4 ft-lbs PAGE 29 RS-2402 ASSEMBLY... -
Page 31: Washer Sizing Chart
CURVED WASHER LOCK WASHER LOCK WASHER LOCK WASHER SPACER 026-01M0238 016-0009003 013-0003002 2" ALUMINUM 1" SHIM WASHER 3/8" FENDER WASHER FLATHEAD CAP 013-0003004 026-01PL151 1 1/16" PLASTIC 1 1/16" FENDER WASHER FENDER WASHER 014-0018002 1" LONG SPACER RS-2402 ASSEMBLY PAGE 30... - Page 32 026-01M0762 026-01M0768 .44" LONG HEAVY 1 1/4" LONG HEAVY 1 1/2" LONG HEAVY FLANGED SPACER FLANGED SPACER FLANGED SPACER 026-01M0239 026-01M0240 1 5/8" ALUMINUM 1 3/8" ALUMINUM FLATHEAD CAP FLATHEAD CAP 026-01M0600 .625" LONG FLANGED SPACER PAGE 31 RS-2402 ASSEMBLY...
-
Page 33: Maintenance Schedule
Your equipment comes with a commercial maintenance decal. For personal, in home use, please follow the home maintenance schedule listed above. Never use ammonia, acid-based, or petroleum-based solvents on any portion of the machine as it may damage the finish. RS-2402 ASSEMBLY PAGE 32... -
Page 34: General Maintenance Information
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL HOIST FITNESS SYSTEMS GENERAL MAINTENANCE INFORMATION Links, Pull-Pins, Snap Hooks, Swivels, Weight Stack Pins: *Check all pieces for signs of visible wear or damage. *Check springs in snap hooks and pull-pins for proper tension and alignment. -
Page 35: Weight Training Tips
Now that you have your RS-2402, it is only natural that you want to get started immediately. First, determine a set of realistic goals and objectives for yourself. By deciding on an exercise plan that is right for you prior to starting, you will contribute significantly to your success. -
Page 36: Exercise Log
OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL OWNER'S MANUAL PAGE 35 RS-2402 ASSEMBLY... -
Page 37: Limited Warranty
Hoist Fitness Systems sole responsibility shall be to repair or replace the component within the terms stated above. Hoist Fitness Systems shall not be liable for any loss or damage of any kind including any incidental or consequential damages resulting, directly or indirectly from any warranty expressed or implied or any other failure of this product.
