- Page 1 BOFA BASE CUBE COMPONENTS HARDWARE PART NO. DESCRIPTION ITEM IMAGE Minifix Floor Bottom Dufix Visible Side Left Visible Side Right Dowel Back Glides TOOLS REQUIRED Screw driver Mallet Measuring tape...
- Page 2 GENERAL INSTRUCTIONS 1. Confirm that all panels (5) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A,B,C,D&E). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below. PANEL CONNECTION AND FASTENING Insert the minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.
- Page 3 ASSEMBLY SHEET - BOFA BASE CUBE STEP 2 STEP 1 E-Back Slide backer along the groove. B-Floor Bottom B-Floor Bottom STEP 3 STEP 4 A-Top A-Top STEP 5 STEP 6 Hammer the glide using a A-Top mallet onto bottom B-Floor Bottom...
