3. GETTING TO KNOW THE AUDIOFUSE X8 OUT

Before we get started using it, let's take a tour around the AudioFuse X8 OUT.

3.1. The Front Panel

The front panel has the following features:
SYNC: selects whether the AudioFuse X8 will accept BNC Word Clock on the rear
•
panel (WORD) or use incoming ADAT sync, either in conventional mode (ADAT)
for 44.1 or 48 kHz input or in SMUX mode (ADAT SMUX) for 88.2 or 96 kHz input.

When neither an ADAT nor Word Clock sync signal is detected, the ADAT LED blinks, indicating that
the AudioFuse X8 OUT is not properly synchronized.

3.1.1. Power button

The round button with the Arturia logo at the far right powers the unit on or off when held
for two seconds. It glows white when the unit is on.

When you power the unit on, all of the front panel LEDs will cycle from left to right. This is the unit's
bootup sequence, and should only take one or two seconds.
6
The AudioFuse X8 OUT front panel
