2. HARDWARE SETUP AND REGISTRATION

Setting up the AudioFuse X8 OUT isn't difficult, but there are a few instructions to follow,
especially if you plan to rackmount it with another X8 OUT or with an X8 OUT.

2.1. What's in the box?

• The AudioFuse X8 OUT
• Rack ear and connecting plate with screws (attached to the bottom of the unit)
• Power supply with adapters for worldwide use
• Registration card with serial number
• Quick Start Guide

2.2. Rackmounting the AudioFuse X8 OUT

The bottom of the unit has a pair of recessed storage positions, one for a single orange
rack ear and one for a square connecting plate. Each has two mounting screws of the
appropriate size.

Note that the connecting plate has four screw holes but only two screws. The extra holes are used
to connect to a second unit using its supplied screws.

The unit comes with mounting screws especially chosen for this purpose. Don't use other screws,
and carefully follow the directions in this manual. You don't want your new converter to fall out of your
rack, do you?
4
Rackmounting components stored under
the AudioFuse X8 OUT
