BluStream Custom Pro Hub 16 Quick Reference Manual page 3

Understanding the Matrix / Receiver Status Lights
The Blustream Matrix and HDBaseT
to show all connections are active, and to help diagnose possible problems. Understanding the status lights:
Blustream Matrix:
™
• The Yellow HDBaseT
specific Matrix output.
™
• The Yellow HDBaseT
™
• The Green HDBaseT link light will blink if there is an unstable connection between the Blustream Matrix and HDBaseT
Receiver
™
• The Green HDBaseT link light will be lit when a there is an active HDBaseT
™
• The Green HDBaseT link light will be off when a there is no connection with a HDBaseT
™
Blustream HDBaseT Receiver:
• The HDMI link light will be off when there is no connection with a display
• The HDMI link light will be on when there is an active connection with a display (Note: Not all HDBaseT
status LED)
™
• The HDBaseT link light will be off when there is no CAT cable/active HDBaseT connection on the RJ45 HDBaseT
™
• The HDBaseT link light will blink if there is an unstable connection between the Blustream Matrix and HDBaseT
™
• The HDBaseT link light will be lit when a CAT cable is connected to the HDBaseT
connection is achieved with the Blustream HDBaseT
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by
the source to find out what audio and video resolutions are supported by the display then from this information the source will
discover what the best audio and video resolutions need to be outputted.
While the objective of EDID is to make connecting a digital display to a source a simple plug and play procedure issues do arise
when multiple displays or video matrix switching is introduced because of the increased number of variables.
By pre-determining the video resolution and audio format of the source and display device you can reduce the time need for EDID
hand shaking thus making switching quicker, and more reliable.
Configuration of Matrix EDID settings can be acheived in one of two ways:
1 Using Matrix web browser interface
2 Using Matrix Front Panel (see below)
To change the input signal type using the Matrix front panel press the following:
Using Matrix Front Panel Buttons:
a. Press the MENU button
b. Matrix front panel will display 'EDID settings'. Press the SELECT button to enter into EDID configuration mode
c. Select the input you wish to fix the EDID on (1-8) or select 'All'. Use UP/DOWN buttons (buttons 4 & 8) to toggle the
selection and press the RIGHT button (button 7) to move to resolution setup
d. Select video resolution required (4K, 1080p, 3D etc). Use UP/DOWN buttons (buttons 4 & 8) to toggle the selection and
press the RIGHT button (button 7) to move to resolution setup
e. Select audio resolution required (2ch, 5.1 or 7.1). Use UP/DOWN buttons (buttons 4 & 8) to toggle the selection and press
the SELECT button to confirm
f. Press the ESC button to exit
contact:
support@blustream.com.au | support@blustream.co.uk
™
extender solutions include status LED indicators on both the Matrix and Receiver products
status link light will be off when the zone output has been turned off or there is a problem with the
status link light will blink when the zone output is on and working
CUSTOM PRO HUB 16
™
Receiver connected to the Matrix
™
Receiver.
QUICK REFERENCE GUIDE
™
receiver
™
RX feature a HDMI
™
RJ45 output on the Matrix and an active
™
™
input
™
receiver
03
