BluStream SW41HDBT Quick Reference Manual

Introduction
FEATURES:
• Features 2 x HDMI 2.0 and 2 x HDBaseT™ inputs which can be switched to simultaneous HDBaseT™ and HDMI
outputs
• Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
• Automatic downscaling of up to 4K 60Hz 4:4:4 video input to 4K 30Hz 4:4:4/4K 60Hz 4:2:0 or 1080p on HDBaseT™
• HDBaseT™ input supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K
@60Hz 4:2:0), HDBaseT™ output supports 4K UHD video up to 40m (3840 x 2160 @60Hz 4:4:4) with compatible CSC
receiver*
• Extends HDMI 1080p up to a distance of 70m from transmitter to SW41HDBT and up to 70m from SW41HDBT to
receiver
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Supports PoC when used with compatible 12V HDBaseT™ transmitters and receivers*
• Compatible with all Blustream HDBaseT™ transmitters and receivers*
• Audio breakout to analogue L/R audio and Toslink (S/PDIF) digital outputs concurrently
• Web interface module for control and configuration of switch
• Manual or auto source selection with control via front panel, IR, RS-232 and TCP/IP
• Auto source selection supported by compatible Blustream HDBaseT™ transmitters only*
• HDCP 2.2 compliant with advanced EDID management
*Technical performance is subject to the features supported on the connected HDBaseT™ transmitter / receiver. Please see
Blustream website or documentation for a list of compatible products.
01
SW41HDBT
Quick Reference Guide
Our SW41HDBT is a 4-Way HDMI 2.0 4K 60Hz 4:4:4 HDBaseT™ switch utilising
CSC technology to deliver HDMI and HDBaseT™ inputs to simultaneous HDMI /
HDBaseT™ output. The SW41HDBT provides enhanced features including PoC
to power Blustream transmitter and receiver products, Web GUI for control and
configuration, source and display control via CEC, manual or automated source
selection, RS-232 pass-through and control via front panel, IR, RS-232 and TCP/
IP. The SW41HDBT is an ideal product for your boardroom, classroom or huddle-
space application when used with our Blustream HDBaseT™ wall-plate solutions.
