Page 1: User Manual
Output Select Input 1 Input 2 Input 3 Input 4 SW41/21AU User Manual... - Page 2 This product contains sensitive electri- cal components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. www.blustream.co.uk...
- Page 3 Multiple switching modes - push-in button, IR remote HDMI output control and IR receiver 3.5mm port on rear panel (Only use compatible Blustream 5V IR products) • SW21 features 2x HDMI inputs that can be switched to single HDMI output •...
- Page 4 Output Audio Out HDMI inputs (SW41 x4, SW21 x2) - Connect to HDMI source device External IR input – Connect Blustream IR sensor or control processor to control switcher HDMI output – Connect to HDMI display device EDID DIP switches – See below settings Coaxial digital output –...
- Page 5 HDMI 4K2K@60Hz, Audio 5.1CH PCM/DTS/DOLBY more reliable. instructions on these settings can be found on the right. [DIP]=1011: HDMI 4K2K@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD [DIP]=1100: DVI 1280x1024@60HZ, Audio None [DIP]=1101: DVI 1920x1080@60HZ, Audio None [DIP]=1110: DVI 1920x1200@60HZ, Audio None contact support@blustream.co.uk / support@blustream.com.au...
- Page 6 SW41/21AU USER MANUAL www.blustream.co.uk...
-
Page 7: Package Contents
SW41/21AU USER MANUAL Package Contents: Maintenance: • 1 x SW41AU / SW21AU Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. • 1x SW41-REMOTE • 1 x 5V/2A DC power supply •... - Page 8 www.blustream.com.au...
