6.2.3 SPI

The board provides an SPI interface and full access to its pinout as it can be seen in the following table.
Pin Function
1 CIPO
2 +5V
3 SCK
4 COPI
5 RESET
6 GND

6.2.4 Digital Pins D22 - D53 LHS

Pin Function
1 +5V
2 D22
3 D24
4 D26
5 D28
6 D30
7 D32
8 D34
9 D36
10 D38
11 D40
12 D42
13 D44
14 D46
15 D48
16 D50
17 D52
18 GND
11 / 27
Type Description
Internal Controller In Peripheral Out
Internal Power Supply of 5V
Internal Serial Clock
Internal Controller Out Peripheral In
Internal Reset
Internal Ground
SPI pinout
Type
Power
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Digital
Power
D22 - D53 LHS pinout
Arduino® Due
Description
+5V Power Rail
GPIO 22
GPIO 24
GPIO 26
GPIO 28
GPIO 30
GPIO 32
GPIO 34
GPIO 36
GPIO 38
GPIO 40
GPIO 42
GPIO 44
GPIO 46
GPIO 48
GPIO 50
GPIO 52
Ground
