6.5 Product Topology

In the following drawing you can see the main integrated circuits and passive components of the Arduino Due
board.
Ref.
U1
USB1
USB2
X2
ERASE
RESET
DEBUG
SPI
ICSP1
15 / 27
Description
Atmel SAM3X8E ARM Cortex-M3
Native USB port
Programming USB port
Power Jack VIN 7-12 VCC
ERASE Button
Reset Button
Debug JTAG pinnout
SPI pinout
ICSPI1 Pinout
Arduino Due Topology
