Uplus Lighting 150 LED BSW User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
150 LED BSW
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 150 LED BSW and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting 150 LED BSW

Summary of Contents for Uplus Lighting 150 LED BSW

  • Page 1 User manual 150 LED BSW Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-10 DMX Channels …………………………………………………………………………………11-13 Trouble Shooting…………………………………………………………………………………13 Fixture Cleaning………………………………………………………… ………………………14 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals.

  • Page 5: Control Menu

    3.Control Menu 1.Operate 1. Operate the luminaire with intuitive touch or assisted input (touch-enabled products) The left area is the TFT display area and the touch area, and by tapping the panel content with your finger or blunt hardware, you can complete things like setting parameters or viewing status. The area on the right is a secondary input, which you can use to select the items you need to set up or view if you don't use TFT's own touch feature.
  • Page 6 2.The determination of the important Boolean parameters is set by the determination window, as shown in Figure 5 below: Subpages (arguments) 1.Function operation and parameter settings Go to the setup interface, as shown in Figure 6-1: In the main interface, you can select six buttons to enter the corresponding parameter settings interface. In the parameter settings interface, you can press the left blue option to quickly switch to another settings interface.
  • Page 7 Lamp reset: Reset all motors. 2.Set the lamp operating mode The operating mode of the luminaire and the control lamp can be set up from the page shown in Figures 6-2. The luminaires support four operating modes(DMX mode, walk-by mode, voice mode, and scene mode), please refer to the previous section for detailed parameter numerical settings, which are described in the following table: Run mode DMX mode...
  • Page 8 Shut down The display is not reversed Open Reverse display automatic Automatic detection of the direction of the lamp hanging lamp, automatic switching of the display direction DMX indicates Set the indication mode of DMX signal indicator Mode 1 On when there is a signal, and off when there is no signal Mode 2 On when there is a signal, when there is no signal, it is on Mode 3...
  • Page 9 X-axis reverse Set the direction of rotation of the X-axis Shut down Not reversed Open reverse Y-axis reverse Set the Y-axis rotation direction Shut down Not reversed Open reverse Optocoupling Set whether the luminaire detects XY out of step and corrects correction Shut down Do not correct the position after the step is lost...
  • Page 10 X-axis Displays the real-time position value of X-axis optical coupling feedback Y-axis Displays the real-time position value of the Y-axis optocoupling feedback Optocoupling Displays the level status of the X and Y axis optocoupled signals, binary Fault / status record Displays the last 8 fault records of the lamp reset and operation, which are not saved after power-down and are valid during the current power-up cycle Fault data...

  • Page 11: Dmx Channels

    4.DMX Channels CH18 Channel name numeric value description X-axis 0-255 0-540 degrees X-axis fine-tuning 0-255 0-2 degrees Y-axis 0-255 0-270 degrees Y-axis fine-tuning 0-255 0-1 degrees XY speed 0-255 From fast to slow Dimming 0-255 0-100% dimming Turn off the light 4-99 From slow to fast pulse strobe Strobe...
  • Page 12 40-44 Pattern 8 45-49 Pattern 9 50-54 Pattern 10 55-64 From slow to fast jitter pattern 1 From slow to fast jitter pattern 65-74 75-84 From slow to fast jitter pattern 3 pattern 85-94 From slow to fast jitter pattern 4 95-104 From slow to fast jitter pattern 5 105-114...

  • Page 13: Trouble Shooting

    CH13 Prism 1 rotation 193-255 Reverse flow from slow to fast 0-127 CH14 atomization 128-255 atomization CH15 Focusing 0-255 From far to near CH16 magnify 0-255 From small to large CH17 function CH18 reposition 251-255 Reset all in more than 5 seconds 5.Trouble Shooting Following are a few common problems that may occur during operation.

  • Page 14: Fixture Cleaning

    6.Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
