PCB Piezotronics IMI SENSORS EX640B00 Installation And Operating Manual page 20

Model Number
640B00
Performance
Measurement Range 0.0 to 0.5 in/sec pk
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Enclosure Rating
Electrical
Excitation Voltage
Load Resistance
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector 2-Pin MIL-C-5015
Electrical Connection Position
Electrical Connections(Pin A)
Electrical Connections(Pin B)
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
EN GLISH SI
0.0 to 12.7 mm/s pk
4-20 mA 4-20 mA
180 to 60 kcpm 3 to 1 kHz
0.005 in/sec pk 0.13 mm/s pk
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
IP68 IP68
12 to 30 VDC 12 to 30 VDC
50 (Vs-12) ohms 50 (Vs-12) ohms
< 15 sec < 15 sec
8 8
> 10 Ohm > 10 Ohm
1.0 in x 2.6 in 25.4 mm x 66 mm
4.7 oz 131 gm
1/4-28 UNF No Metric Equivalent
3 to 5 ft-lb 4 to 7 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015
Top Top
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
Optional versions have identical specifications and accessories as listed for the standard model
[1]
except where noted below. More than one option may be used.
[2][3] - Hazardous Area Approval- contact factory for
EX
specific approvals
[4]
M - Metric Mount
RV - Buffered Analog Signal Output - 100 mV/g
(±20%)
Electrical Connector
Electrical Connections(Pin A)
Electrical Connections(Pin B)
Electrical Connections(Pin C)
N OTES:
[1]Conversion Factor 1 in/sec = 0.0254 m/sec.
[2]Current will fluctuate at frequencies below 5 Hz.
[3]1Hz = 60 cpm (cycles per minute).
[4]Typical.
[5]See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor (1)
Entered: ND Engineer: gs
Date: 04/13/2021 Date: 04/13/2021 Date: 04/13/2021 Date: 04/13/2021 27201
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 51673
OPTION AL VERSION S
3-Pin MIL-C-5015 3-Pin MIL-C-5015
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg/Signal Output 4-20 mA Neg/Signal Output
Neg Neg
Signal Output Pos Signal Output Pos
Sales: JL Approved: BAM Spec Number:
Phone: 800-959-4464
Fax: 716-684-3823
E-M ail: imi@ pcb.com
