RTC battery connector
4
Connector
Black mark sensor connector (Roll side)
5
6
Black mark sensor connector (TPH side)
Pin
Description
1
GND
2
Head open sensor receiver
Pin
Description
1
GND
2
3V
Description
Pin
Description
1
Black mark sensor emitter
2
Black mark sensor receiver
3
3.3V
4
GND
CON18
Remark
CON7
CON8
6
