Laptop Tray and Desk Mount with RGB Fan
Instruction Manual
SKU: STAND-V001LF
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001lf
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V001LF and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V001LF

  • Page 1 Laptop Tray and Desk Mount with RGB Fan Instruction Manual SKU: STAND-V001LF Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001lf GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Tools Needed

    If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3: Package Contents

    PACKAGE CONTENTS A (x1) B (x1) C (x1) D (x1) E (x1) Pole Clamp VESA Plate Laptop Tray F (x1) G (x1) H (x2) I (x1) J (x1) Grommet Base Soft Pad Arm Cable Clip Pole Cable Clip Pole Cap K (x2) L (x2) Laptop Arm...
  • Page 4 STEP 2 (Option A) Desk Clamp Install Loosen Clamp Bolt (B1) on Clamp (B). Install Clamp (B) to Pole (A) using M6x16 Screws (S-A) and 3mm Allen Wrench (T-A). Secure the clamp assembly to the desktop.
  • Page 5 STEP 2 (Option B) Grommet Install Using a Phillips screwdriver, remove the screw from Clamp (B) and separate Clamp Bolt (B1) and Clamp Plate (B2) from the clamp assembly. Thread Clamp Plate (B2) onto Blamp Bolt (B1). Install Grommet Base (F) to Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A).
  • Page 6 STEP 3 Slide Pole Cable Clip (I) and Arm (C) over Pole (A). Secure Arm (C) at the desired height using 5mm Allen Wrench (T-B). Insert Pole Cap (J) into the top of Pole (A). STEP 4 Attach Arm Cable Clips (H) to Arm (C).
  • Page 7 STEP 5 Install Laptop Arms (K) onto the Laptop Tray (E) using Latches (L). Lay Latches (L) over the Laptop Tray (E) with one set of the hooks aligned with the slot on the tray and the other offset from the edge of the tray.
  • Page 8 STEP 6 Install the Laptop Tray (E) to VESA Plate (D) using the M4x12mm Screws (S-C) and M5 Washers (M-D). Tighten the screws using a Phillips screwdriver. STEP 7 Slide VESA Plate (D) onto Arm (C) and secure using M6 Nut (S-B).
  • Page 9 STEP 8 Adjust the Laptop Tray (E) size by pulling down the levers on Laptop Arms (K). Adjust the arms to your desired width and press the levers back in to secure. Plug the USB-A cable into any 5V power supply to power the fan and RGB lighting.
  • Page 10 OPTIONAL USE: MONITOR MOUNT To use stand as single monitor mount, follow Steps 1-4, then return to these instructions to proceed. STEP 5 Attach VESA Plate (D) to the back of the monitor using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B) with M4 Spacers (M-C). Slide VESA Plate (D) with the monitor onto Arm (C).
  • Page 11 STEP 6 Manage cables using Arm Cable Clips (H) and Pole Cable Clip (I). STEP 7 Adjust the tilt using 5mm Allen Wrench (T-B).
  • Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
