- Page 1 Single Monitor Extra Tall Desk Mount STAND-V001T Series Assembly Manual Individual Product SKUs STAND-V001T STAND-V001TW...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 3: Package Contents
Package Contents A (x1) B (x1) C (x1) D (x1) Bottom Pole Top Pole Clamp E (x1) F (x1) G (x2) H (x1) Grommet Plate Pole Connector Cable Clip Pole Cap I (x5) J (x1) Support Plate Soft Pad Included Hardware & Tools S-A (x3) M-A (x4) M-B (x4) -
Page 4: Assembly Steps
Assembly Steps STEP 1 Insert Pole Cap (H) into Top Pole (C). -
Page 5: Option 1: Clamp Assembly
STEP 2 Option 1: Clamp Assembly 1.1 Desktop Thickness: 0.40” - 3.35” (10mm - 85mm) Install Clamp (D) to Bottom Pole (B) using M6x16mm Screws (S-A) and tighten using 3mm Allen Wrench (T-A). Remove the adhesive backing from Soft Pads (I) and place them on the underside of Clamp (D). - Page 6 Option 2: Grommet Assembly For Desktop Thickness .39 - 2.95” (10mm - 75mm) Remove the adhesive backing from Using 4mm Allen Wrench (T-B), Soft Pads (I) and place them on the disassemble Clamp (D). underside of Grommet Plate (E). Remove Clamp Plate (D1) using Place Bottom Pole (B) ontop of Grommet Plate (E).
- Page 7 STEP 3 Thread Pole Connector (F) into Bottom Pole (B), then thread Top Pole (C) into Connector. Secure by tightening the set screws on Pole Connector using 3mm Allen Wrench (T-A). Poles Won’t Thread Into Connector? If you have trouble threading Poles (B,C) into the Pole Connector, slightly loosen the two Set Screws on the connector by using a 3mm Allen Wrench and turning counter-clockwise.
- Page 8 STEP 4 Loosen the Screw on the back of Arm (A) using the 5mm Allen Wrench (T-C). Slide Cable Clip (G) and Arm down the Top Pole. Screw Screw Retighten the Screw on Arm using the 5mm Allen Wrench when desired position is reached.
- Page 9 STEP 5 Install Screws (M-A, M-B) and M5 Washers (M-C) to the top of your monitor’s mounting holes. Make sure to leave 3mm of thread exposed. 2 Person Mounting Recommended Align previously installed Screws with the top of VESA Plate. Secure using two more Screws and M5 Washers in the bottom two holes.
- Page 10 STEP 6 Store Allen Wrenches (T-A thru T-D) in Cable Clips (G).
-
Page 11: Tilt Tension Adjustment
Adjustments Tilt Tension Adjustment Adjust vertical tilt tension in the monitor bracket by using 6mm Allen Wrench (T-D). Adjust as Desired Monitor mount can be turned to support a vertical display. - Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
