Laptop Tray and Desk Mount
Instruction Manual
SKU: STAND-V001LU
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001lu
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V001LU
Summary of Contents for Vivo STAND-V001LU
- Page 1 Laptop Tray and Desk Mount Instruction Manual SKU: STAND-V001LU Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001lu GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Tools Needed
If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Package Contents
PACKAGE CONTENTS A (x1) B (x1) C (x1) D (x1) E (x1) Pole Clamp VESA Plate Laptop Tray F (x1) G (x1) H (x2) I (x1) J (x1) Grommet Base Soft Pad Arm Cable Clip Pole Cable Clip Pole Cap K (x1) L (x1) USB Hub... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Option A: Desk Clamp Install Loosen Clamp Bolt (B1) on Clamp (B). Install Clamp (B) to Pole (A) using M6x16 Screws (S-D) and 3mm Allen Wrench (T-A). Secure the clamp assembly to the desktop. - Page 5 STEP 1 - Continued Option B: Grommet Install Using a Phillips screwdriver, remove the screw from Clamp (B) and separate Clamp Bolt (B1) and Clamp Plate (B2) from the clamp assembly. Thread Clamp Plate (B2) onto Blamp Bolt (B1). Install Grommet Base (F) to Pole (A) using M6x16mm Screws (S-D) and 3mm Allen Wrench (T-A).
- Page 6 STEP 2 Slide Pole Cable Clip (I) and Arm (C) over Pole (A). Secure Arm (C) at the desired height using 5mm Allen Wrench (T-B). Insert Pole Cap (J) into the top of Pole (A). STEP 3 Attach Arm Cable Clips (H) to Arm (C).
- Page 7 STEP 4 Assemble VESA Plate (D) to Laptop Tray (E) using M4x8mm Screws (S-A) and M4 Nuts (S-B). Tighten using Wrench (T-C) and a Phillips screwdriver. Assemble USB Hub (K) to Laptop Tray (E) using M3x8mm Screws (S-E), tightening with a Phillips screwdriver.
- Page 8 STEP 6 Swivel and tilt assembled laptop tray to desired angle. STEP 7 Assembly is now complete. Place laptop on tray. Use Velcro Strap (L) to manage USB Hub Cable (K1).
- Page 9 OPTIONAL USE: MONITOR MOUNT To use stand as single monitor mount, follow Steps 1-3, then return to these instructions to proceed. STEP 4 Attach VESA Plate (D) to the back of the monitor using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B) with M4 Spacers (M-C). Slide VESA Plate (D) with the monitor onto Arm (C).
- Page 10 STEP 6 Manage cables using Arm Cable Clips (H) and Pole Cable Clip (I). STEP 7 Adjust the tilt using 5mm Allen Wrench (T-B).
- Page 11 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
