Single Monitor Desk Stand
Instruction Manual
SKU: STAND-V001H
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001h
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V001H
Summary of Contents for Vivo STAND-V001H
- Page 1 Single Monitor Desk Stand Instruction Manual SKU: STAND-V001H Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001h GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach the pole cap (E) to the top of the pole (D). STEP 2 Use the 4mm Allen wrench (I) to tighten the screws (H) into the pole from the bottom of the base (C). - Page 4 STEP 3 Slide the cable clip (F) onto the pole. Slide the mounting bracket (B) onto the pole. Tighten the mounting bracket (B) on the pole using a 6mm Allen wrench (J).
- Page 5 STEP 4 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor For flat back monitor, secure VESA plate (A) to For monitor with curved or recessed back, align monitor using screws (M-A or M-C) and washers spacers (M-F) with mounting holes in monitor, (M-E).
- Page 6 STEP 6 Tighten or loosen tilt joint using 6mm Allen wrench (J). STEP 7 Manage cables with installed cable clip.
- Page 7 STEP 8 Store tools in cable clip. STEP 9 Adjust monitor position and rotation. 180 ° +45 ° 360° -45°...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
