Foam seal A
Foam seal B
(Adhesive type)
(Adhesive type-shorter)
Hung Window Installation
Foam seal A Foam seal B
(Adhesive type) (Adhesive type-shorter)
Sliding Window Installation
NOTE: Once the exhaust hose
assembly and adjustable window
slider are prepared, choose one
of the two installation methods
based on your window type.
3. Complete sealing of window
Cut the adhesive foam seal A and B strips to the
proper lengths, and attach them to the window
sash and frame as shown.
4. Hung Window Installation
S e t p : 1
Insert the window slider assembly into the window
opening.
S e t p : 2
Cut the non-adhesive foam seal C strip to match the
width of the window. Insert the seal between the glass
and the window frame to prevent air and insects from
getting into the room.
Step 3:
If desired, install the security bracket with 2 screws as
shown.
