Product Overview
NOTICE
All the illustrations in the manual are for explanation purpose only. Your machine may
be slightly di erent. The actual shape shall will remain the same.
The unit can be controlled by the unit control panel alone or with the remote control.
Front View
DESIGN NOTICE
In order to ensure the optimal performance of our products, the design specifications
of the unit and remote control are subject to change without prior notice.
Control panel
Horizontal louver blade
(swing automatically)
Front panel
Caster
11
Upper air filter
(behind the grille)
Upper air intake
Drain outlet
Air outlet
Lower air filter
Lower air intake
Power plug socket
Power cord buckle
Bottom tray
drain outlet
Rear View
