Confirm Your Window Type (Window Type And Opening Size Of
Different Types)
Sliding Window Installation Hung Window Installation
For Optimal Performance In Operation
NOTICE
To ensure proper function, DO NOT overextend or bend the hose. Make sure that there
is no obstacle around the air outlet of the exhaust hose (in the range of 500mm) in
order to ensure the exhaust system works properly. All the illustrations in this manual
are for explanation purpose only. Your air conditioner may be slightly different. The
actual shape shall prevail.
INCORRECT CORRECT
14
