SECTION 6
6.1. Requirements for 12V DC Operators
Additional wiring required for Auxiliary and Status LED
6.2. Requirements for 24V DC Operators
Additional wiring required for Auxiliary and Status LED
24V-12V DC
Regulator Board
Two-wire Bus
FIGURE 28. WIRING REQUIREMENTS FOR 12V DC OPERATORS
Two-wire Bus
+12V DC Out
-12V DC Out
+24V DC in
FIGURE 29. WIRING REQUIREMENTS FOR 24V DC OPERATORS
+12VDC
-12VDC
TRG
TRG
COM
page 21
WIRING
