  • Page 1 INTERCOMS METAL GATE STATION INSTALLATION MANUAL Centurion Systems (Pty) Ltd www.centsys.com...
  • Page 2 Saturdays 08h00 to 14h00 GMT+2 Centurion Systems (Pty) Ltd reserves the right to make changes to the product described in this manual without notice and without obligation to notify any persons of any such revisions or changes. Additionally, Centurion Systems (Pty) Ltd makes no representations or warranties with respect to this manual.
  • Page 3: Table Of Contents

    4.2. Mounting the Metal Gate Station onto a Gooseneck Page 11 COMPLETING THE INSTALLATION Page 12 5.1. Wiring a G-SPEAK ULTRA to the Metal Gate Station Page 12 5.1.1. DX Controller Page 12 5.1.2. D5ES Controller Page 13 5.1.2. D-Series Controller Page 14 5.1.4.
  • Page 4: Introduction

    Do not leave packing materials (plastic, polystyrene, etc.) within reach of children as such materials are potential sources of danger • Neither Centurion Systems (Pty) Ltd, nor its subsidiaries, accepts any liability caused by improper use of the product, or for use other than that for which the system was intended •...
  • Page 5: Technical Specifications

    SECTION 2 SPECIFICATIONS 2. SPECIFICATIONS 2.1. Physical Dimensions 40mm 97mm FIGURE 1. METAL GATE STATION PHYSICAL DIMENSIONS 2.2. Technical Specifications METAL GATE STATION Operating voltage 7.4V DC as supplied by the G-SPEAK ULTRA Current draw 11mA Speech volume Adjustable via G-WEB...
  • Page 6: Product Identification

    Metal Gate Station Cover Wall Plug Hex Socket Countersunk Screw M5x25 Cap Screw Hex Socket Cap Screw Gooseneck Backing Plate Metal Gate Station PCB 10. M5 Nyloc Nut Self Tapping Screw 11. M5 Washer Metal Gate Station Rear Housing page 6 www.centsys.com...
  • Page 7: Physical Installation

    SECTION 4 PHYSICAL INSTALLATION 4. PHYSICAL INSTALLATION 4.1. Mounting the Metal Gate Station onto a Wall The following steps should only be performed once the G-SPEAK ULTRA has been successfully wired into your operator. Hex Socket Countersunk Screw 1. Remove the four Hex Socket...
  • Page 8 Metal Gate Station Rear Housing FIGURE 6 POINT A 5. Once the Metal Gate Station PCB has been removed, there will be two points which you can use to run your cables through, to wire the Metal Gate Station to your G-SPEAK ULTRA.
  • Page 9 Housing FIGURE 9 Metal Gate Station PCB 10. Wire your cables to the Wiring Block on the Metal Gate Station PCB and fit it back into the Metal Gate Station Rear Housing using the inverse movements of step 4. Wiring...
  • Page 10 FIGURE 12 Metal Gate Station Rear Housing Metal Gate Station Cover 16. Place the Metal Gate Station Cover back onto the Metal Gate Station Rear Housing and ensure that all components are propely clipped together. FIGURE 13 Hex Socket...
  • Page 11: Mounting The Metal Gate Station Onto A Gooseneck

    SECTION 4 PHYSICAL INSTALLATION 4.2. Mounting the Metal Gate Station onto a Gooseneck The following steps should only be performed once the G-SPEAK ULTRA has been successfully wired into your operator. Hex Socket Countersunk Screw Step 1 - 4 Refer to page 7 and 8 (follow step 1- 4).
  • Page 12: Completing The Installation

    SECTION 5 COMPLETING THE INSTALLATION 5. COMPLETING THE INSTALLATION 5.1. Wiring a G-SPEAK ULTRA to the Metal Gate Station 5.1.1. DX Controller G-SPEAK ULTRA DX Control Card VIN NEG The I/Os are configured using MyCentsys Pro. • I/O1 - TRG •...
  • Page 13: D5Es Controller

    5.1.2. D5ES Controller G-SPEAK ULTRA D5ES Control Card VIN NEG The I/Os are configured using MyCentsys Pro. • I1 - TRG • I2 - PED • I/O4 - Gate Status • I/O5 - Alarm Metal Gate Station FIGURE 19 page 13 www.centsys.com...
  • Page 14: D-Series Controller

    SECTION 5 COMPLETING THE INSTALLATION 5.1.3. D-Series Controller G-SPEAK ULTRA D-Series Control Card Do not mount close to the DOSS sensor or remote receiver. VIN NEG Metal Gate Station FIGURE 20 page 14 www.centsys.com...
  • Page 15: Vx Smart Controller

    VIN NEG The I/Os are configured using MyCentsys Pro. • I1 - TRG • I2 - PED • I/O4 - Gate Status • I/O5 - Alarm Metal Gate Station FIGURE 21 page 15 www.centsys.com...
  • Page 16: Warranty Information

    4. Has been repaired by any workshop and / or person NOT previously authorised by the manufacturer. 5. Has been repaired with components not previously tested, passed or authorised by Centurion Systems (Pty) Ltd, South Africa or one of its subsidiary companies. page 16 www.centsys.com...
  • Page 17 The CENTURION and CENTSYS logos, all product and brand names in this document that are accompanied by the TM symbol are trademarks of Centurion Systems (Pty) Ltd, in South Africa and other territories; all rights are reserved. We invite you to contact us for further details.
