CENTURION SYSTEMS G-SPEAK ULTRA Instructions Manual

Hide thumbs Also See for G-SPEAK ULTRA:

Advertisement

Quick Links

Download this manual
G-SPEAK ULTRA
QUICK GUIDE
Centurion Systems (Pty) Ltd
www.centsys.com
GSM DEVICES

Advertisement

loading
Need help?

Need help?

Do you have a question about the G-SPEAK ULTRA and is the answer not in the manual?

Questions and answers

Related Manuals for CENTURION SYSTEMS G-SPEAK ULTRA

Summary of Contents for CENTURION SYSTEMS G-SPEAK ULTRA

  • Page 1 GSM DEVICES G-SPEAK ULTRA QUICK GUIDE Centurion Systems (Pty) Ltd www.centsys.com...
  • Page 2 Saturdays 08h00 to 14h00 GMT+2 Centurion Systems (Pty) Ltd reserves the right to make changes to the product described in this manual without notice and without obligation to notify any persons of any such revisions or changes. Additionally, Centurion Systems (Pty) Ltd makes no representations or warranties with respect to this manual.
  • Page 3 Page 12 6.2.2. DIN-rail Mounting Page 12 WIRING DIAGRAMS Page 14 7.1. G-SPEAK ULTRA to 24V Dx Series SMART Controllers Page 14 7.2. G-SPEAK ULTRA to 12V D5-Evo SMART Controllers Page 15 7.3. G-SPEAK ULTRA to 12V Vx Series SMART Controllers Page 16 7.4.
  • Page 4 INTRODUCTION 1. Introduction Take your security to new heights with the G-SPEAK ULTRA. This innovative GSM intercom system allows you to answer your intercom from anywhere in the world, ensuring maximum convenience and peace of mind. By seamlessly integrating wireless GSM technology with a futuristic ULTRA interface, the G-SPEAK ULTRA offers wireless communication between you and the intercom gate station.
  • Page 5 SECTION 2 SPECIFICATIONS 2. Specifications 2.1. Physical Dimensions 114.4mm 33mm FIGURE 1. G-SPEAK ULTRA PHYSICAL DIMENSIONS 2.2. Technical Specifications Supply Voltage Range 11-24V DC Maximum current draw 300mA @ 12V DC Input/output current rating 50mA (Open Collector) 0-24V DC Input sense voltage range (0-1.6V Low-input State, 5V-24V High-input State)
  • Page 6 SECTION 2 SPECIFICATIONS 2.2. Technical Specifications Continued • 100 Visitor Time-barring Windows (Windows are the periods between two dates) • 30 Generic Time-barring Windows (Windows are weekly recurring) Memory capacity • 10 Output Activation Schedules (continued) (Schedules are weekly recurring) •...
  • Page 7 SECTION 3 PRODUCT IDENTIFICATION 3. Product Identification FIGURE 2. PRODUCT IDENTIFICATION Fascia Terminal Blocks External Antenna Cover Navigation Panel Main G-SPEAK ULTRA unit LCD Screen Mounting Plate page 7 www.centsys.com...
  • Page 8 SECTION 4 REQUIRED TOOLS AND EQUIPMENT 4. Device Layout and Wired Connections NanoSIM Card Optional: External Antenna NOTE: The Internal Antenna is selected by default. Enter / Home Scroll Left Scroll Right FIGURE 3. DEVICE LAYOUT 1. For Austraila and New Zealand only: Requires either Standard Antenna (WH-GHQ918D) or High-performance Antenna (WH-GSM05SMA2) VIN NEG FIGURE 4.
  • Page 9 SECTION 5 LCD INTERFACE 5. LCD Interface Home Screen Network Name or Phone Number Applicable to Incoming / Outgoing SMS or Call. Network Signal Strength Connected to Internet Connected to G-WEB Device has Error Condition Incoming SMS Outgoing SMS Incoming Phone Call Events Outgoing Phone Call Events IO Status Screen Input: Deactivated (“E”...
  • Page 10 SIM Screen PIN: SIM PIN OK SIM PIN Incorrect SIM Error IMEI Screen G-SPEAK ULTRA 12 34 5678 9012 345 Displays the device’s IMEI number Gate Station Voice Numbers +2781 234 5678 Displays the primary and secondary Voice Numbers allocated to their respective buttons...
  • Page 11 (as shown in Figures 4 and 5), and pulling outward and upward. Mounting Plate Slots FIGURE 6 G-SPEAK ULTRA Fascia The fascia should pop off without effort. Main G-SPEAK ULTRA Unit FIGURE 7 Reverse the procedure under Section 6.1 to re-assemble the G-SPEAK ULTRA. page 11 www.centsys.com...
  • Page 12 CONFIGURATIONS 6.2. Installation 6.2.1. Wall Mounting Mounting Screws (not suppiled) The Mounting Plate is used to mount the G-SPEAK ULTRA device to a wall. Use four screws with wall anchors (not supplied) to secure Mounting Plate. Wall Anchors Mounting Plate...
  • Page 13 A ‘click’ will be heard if it Position A has been done correctly(B). Clip the G-SPEAK ULTRA main unit DIN-Rail into the Mounting plate after it has been secured to the wall; another "click"...
  • Page 14 SECTION 7 WIRING DIAGRAMS 7. Wiring Diagrams 7.1. G-SPEAK ULTRA to 24V Dx Series SMART Controllers Possible Activations Possible Notifications • Trigger Open • Gate Open / Closed • Pedestrian Open • Gate Opening / Closing • Free Exit / Keep Open •...
  • Page 15 SECTION 7 WIRING DIAGRAMS 7.2. G-SPEAK ULTRA to 12V D5-Evo SMART Controller Possible Activations Possible Notifications • Trigger Open • Gate Open / Closed • Pedestrian Open • Gate Opening / Closing • Free Exit / Keep Open • Gate Standing Open •...
  • Page 16 SECTION 7 WIRING DIAGRAMS 7.3. G-SPEAK ULTRA to 12V Vx Series SMART Controllers Possible Activations Possible Notifications • Trigger Open • Gate Open / Closed • Pedestrian Open • Gate Opening / Closing • Free Exit / Keep Open • Gate Standing Open •...
  • Page 17 SECTION 7 WIRING DIAGRAMS 7.4. G-SPEAK ULTRA to 12V D-Series Controllers Possible Activations Possible Notifications • Trigger Open • Gate Open / Closed • Pedestrian Open • Gate Opening / Closing • Free Exit / Keep Open • Gate Standing Open •...
  • Page 18 SECTION 7 WIRING DIAGRAMS 7.5. G-SPEAK ULTRA to 12V V-Series Controllers Possible Activations Possible Notifications • Trigger Open • Gate Open / Closed • Pedestrian Open • Gate Opening / Closing • Free Exit / Keep Open • Gate Standing Open •...
  • Page 19 • The Status and alarm inputs must have three seconds filter time configured on the G-SPEAK ULTRA • The strobe output on the energiser needs to be programmed for the armed status notification to be sent via the G-SPEAK ULTRA page 19 www.centsys.com...
  • Page 20 FIGURE 19 The Alarm Panel PGMs must activate to “GND”. However, if the Alarm Panel only supports positive activations, then relays must be used between the Alarm Panel and the G-SPEAK ULTRA to change the activation to “GND”. page 20 www.centsys.com...
  • Page 21 SECTION 7 WIRING DIAGRAMS 7.8. G-SPEAK ULTRA into a Striker Lock Possible Activations Possible Notifications • Lock / Unlock • Lock Status G-SPEAK ULTRA VIN NEG +12VDC Solenoid Lock 3A relay FIGURE 20 page 21 www.centsys.com...
  • Page 22 Navigate your Internet browser to http://www.gweb.co.za (or www.g-web.com.au for Australia and New Zealand) and login to your existing profile or, alternatively, register a new profile. On the My Devices page, select Add New G-SPEAK ULTRA Device and follow the onscreen instructions to associate the device to your profile.
  • Page 23 4. Has been repaired by any workshop and / or person NOT previously authorised by the manufacturer. 5. Has been repaired with components not previously tested, passed or authorised by Centurion Systems (Pty) Ltd, South Africa or one of its subsidiary companies. page 23 www.centsys.com...
  • Page 24 The CENTURION and CENTSYS logos, all product and brand names in this document that are accompanied by the TM symbol are trademarks of Centurion Systems (Pty) Ltd, in South Africa and other territories; all rights are reserved. We invite you to contact us for further details.
