Healtech ESC-A01 User Manual

ES Calibrator
1. Foreword
Before using this product, please ensure the bike
is compatible with this tool. Check the part number
on the packaging and use the Product Advisor
on our website to check compatibility. For more
information on this product, please visit:
www.healtech-electronics.com/ESC
Congratulations on your purchase of an ES
Calibrator (ESC) module. Products from HealTech
Electronics Ltd. are the most advanced aftermarket
accessories and maintenance tools for motorcycles.
The ES Calibrator is designed especially for recent
Aprilia motorcycles and enables an effortless,
straightforward exhaust servo motor calibration
with or without the original servo motor being in
place.
2. Features
 Time-saving and effortless calibration
Enables exhaust servo motor calibration without
the need to reconnect the original servo motor!
Save on service bills! The ESC is an economical
solution for bike owners who carry out their own
maintenance.
Save on servicing time! It is much quicker and
more convenient to use the ESC module for servo
calibration than using a dedicated diagnostic
tool. Faster turnaround and lower costs even for
workshops.
3. Warranty
HealTech Electronics Ltd. guarantees this product
against defects in material and workmanship for a
period of two (2) years.
4.
Specifications
- Supply voltage: +8V to +18V
- Max. supply current at 12V: 60 mA
- Operating temp: -40°C to +80°C (-40°F to +176°F)
ES Calibrator User Manual [rev. 001]
Exhaust servo calibrator module | Model: ESC-A01
User Manual
There are two usage scenarios when the ES
Calibrator can come in handy:
Scenario A) The exhaust servo and exhaust valve
are in place and work normally, but requires
calibration for proper, error-free operation.
Scenario B) The exhaust servo motor has been
replaced with a HealTech Exhaust Servo Eliminator
(ESE) module, but the ECU still gives an error code
for the exhaust servo motor (due to it was out of
calibration the last time it was used). In this case,
the ESC will calibrate the ECU to accept the ESE
module as the new (virtual) servo motor. There's
no need to re-install the original servo motor and
exhaust valve. The ESC will clear the FI error code
when the calibration process is completed.
 Quick and simple to use
Just plug the ESC module into the diagnostic
connector, turn the ignition key ON and wait a few
seconds to see the result on the bicolor status LED.
 Built to last
- Rugged design, encased in epoxy resin.
- Only high-quality SMD components are used.
- Each unit is extensively tested before shipping.
- Oil and water resistant (IP68).
 Light and small
The ESC module is hardly larger than the OEM
diagnostic connector it connects to.
The warranty period starts from the date of the
original purchase as shown on the invoice.
- Waterproof (IP68)
- Unit size: 20 x 30 x 13 mm (1.2" x 0.8" x 0.5")
- Reverse polarity and transient protection
| www.healtech-electronics.com/ESC 1/2
