Install Guide for
For use with the following DUCATI motorcycles:
Hypermotard
(2007-2010),
ST4s
(2004-2007),
999
(2008-2010),
(2003-2006),
Also fits MV AGUSTA F4
Disclaimer: Do not attempt to install the product if you don't have basic mechanical skills.
The SpeedoHealer is intended to improve speedometer accuracy. However, HealTech
Electronics Ltd. and its distributors shall not be liable for any loss, damage or penalties
caused by improper installation or inaccurate speed readings.

1. Locating the Speed Sensor coupler

Preparation:
- The ignition key should be in OFF position.
- Raise the rear wheel off the ground by using a stand.
Make sure the rear wheel spins freely.
- Remove the seat.
Ducati: The Speed Sensor is mounted at the rear wheel. Trace the cable from the
sensor until you find the 3-pole black speed sensor connector. The connector is usually
accessible by removing the right side fairing and on most models it is in close proximity
of the right side engine cover.
MV Agusta: the connector is at the front sprocket cover.
If in doubt, check the bike's Service Manual or ask your dealer for the location of the
Speed Sensor coupler.
Confirmation:
Separate the Speed Sensor coupler (you might need to use a small flathead screwdriver
to get the coupler apart). Rotate the rear wheel while the ignition is on.
Does the speedometer show 0, turn the ignition off and proceed to the next step.
Otherwise, try again since you have disconnected something else.
SHv4_D01_InstallGuide_en.pdf
http://www.speedohealer.com
Monster
Streetfighter
(2004-2005),
1098
(2007-2009),
(2003-2010),
[rev. 003]
Harness Kit
SH-D01
Multistrada
(2003-2010),
(2009-2010),
1198
(2009-2010)
Brutale
(2004-2010)
ST3
(2003-2010),
749
848
(2003-2006),
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Speedohealer v4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Healtech Speedohealer v4

  • Page 1 Disclaimer: Do not attempt to install the product if you don’t have basic mechanical skills. The SpeedoHealer is intended to improve speedometer accuracy. However, HealTech Electronics Ltd. and its distributors shall not be liable for any loss, damage or penalties caused by improper installation or inaccurate speed readings.
  • Page 2 2. Installation After separating the Speed Sensor coupler, plug in both the male and female 3-pole SH harness connectors. Make sure the connectors are fully seated. Connect the 4-pole SH harness connector to the SH box. Check whether the SH is installed and working properly: Have the ignition OFF.
